The Hager Orion.Tech steel enclosure 300x300x160 mm with plain single door secures control and distribution equipment for indoor use. Rated IP65 and IK10 for dust/water sealing and impact resistance, with Class I insulation. Powder-coated RAL7035 steel, 2 mm sidewalls. Wall-mounted with 2 flange openings. Secure 3-point 8 mm key locking and 2 locks. Light grey finish.

EAN

3250612510306

VPE

1 piece

Steel enclosure Orion.Tech IP65 IK10 plain door 300x250x160 wall-mount FL703L

Accessories
Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

product.page.accessories.title

Accessories/spare parts for low-voltage switch technology 1 product.page.accessories.products-available
Accessories/spare parts for earthing and lightning 1 product.page.accessories.products-available

Technical characteristics

Height

300 mm
Width

300 mm
Depth

160 mm
Thickness of sidewall

2 mm

Ingress Protection (IP) class

IP65
Protection class

Isolation class I
Locking type

3-Side 8 mm, Key lock
Impact resistance IK

IK10

Number of flange plate openings

2

Mounting on

Wall mounting
Suitable for outdoor usage

No

Colour

Light grey
RAL code

7035
Treatment

Powder coated
Material

Steel

Number of cabinet doors

1
Number of locks

2
Door/cover is transparent

No
Cabinet door type

Single door

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

Halogen free Yes
