The Hager 1-Phase kWh meter, MID approved, measures energy on direct-connected circuits up to 80A in just 2 modules. With 1P+N wiring, Class B accuracy and S0 pulse output, it enables compliant billing and easy integration with monitoring systems. DIN-rail mounted, electronic direct measurement (0.25-80 A, 92-276 V, 45-65 Hz). Ideal for residential or commercial sub-metering.

EAN

3250612231386

VPE

1 piece

Data Act Notice

kWh meter 1P+N 40A Direct 1 Module S0 MID Class B ECP180D

Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

Technical characteristics

Type of pole

1P+N

Rated current IN

80 A
Maximum measuring circuit current

80 A

Number of modules

2

Type of connection

Direct connection

Height

92 mm
Width

36 mm
Depth

60 mm

Type of pulse generator

Electrical

Suitable for

Purchase/supply

Cross-section of metering input

33 - 33 mm²
Cross-section of metering output

33 - 33 mm²

Nominal tightening torque

2 - 2 Nm
Mounting on

DIN rail

Nominal tightening torque digital terminal

0.50 - 0.50 Nm

Measuring system

Direct measurement
Type of measuring instrument

Electronic
Current measurement range

0.25 - 80.0 A
Measurement range voltage Ph-N

92 - 276 V
Frequency measuring range

45 - 65 Hz

Number of phases for power supply

1

Accuracy class

B
Tariff type

T1...T2 (230 V AC)/-
Is calibrated

Yes

Ingress Protection (IP) class

IP20

Operating temperature

-25 - 55 °C
Storage/transport temperature

-25 - 70 °C

Power consumption (VA)

2 VA
Power dissipation at IN

1 W

Frequency

50 - 50 Hz

Is generating data

Yes
Real time data generation

No
Data stored on device

No

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
