The Hager BA6 slotted panel trunking 40x60 mm in stone grey (RAL7030) organizes and protects wiring in control panels and switchboards. Made of self-extinguishing PVC (UL94 V0, M1), it includes a cover. 2 m length with 4 mm slits/6 mm slots enables easy cable entry/exit and secure fastening. Rigid design ensures clean, durable installations.
EAN
4012740102926
Packaging
40 Meters
Slotted panel trunking PVC BA6 40x40 stone grey RAL7030 UL94 V0 2m cover BA64006007030B
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Spacer sleeve 2 products available -
Draper hand riveter 3 products available -
Screw rosette 1 products available -
Shears for cutting trunking 1 products available
Complete your system
Technical properties
Dimensions
-
Height43 mm
-
Width67 mm
-
Length2000 mm
-
Slit width4 mm
-
Slot width6 mm
-
Inner cross-section2546 - 2546 mm²
Equipment
-
Cover in scope of deliveryYes
Materials
-
MaterialPolyvinylchloride (PVC)
-
ColourStone grey
-
RAL code7030
Functions
-
Is self-extinguishingYes
Standards
-
Flammability class according UL94V0
Safety
-
Fire resistance classM1
Architecture
-
FlexibleNo
Configuration
-
Side wallSlotted
Connectivity
-
Mounting typeScrew mounting, Rivet mounting
Installation, mounting
-
Mounting onMounting plate
Electric current
-
Is current leak stableYes
