Fuse comb. switch 4P - 160 A / T00 HFD416
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Accessories/spare parts for low-voltage switch technology 1 products available -
Auxiliary contact block 2 products available -
Terminal cover 1 products available -
Switch operating shaft 2 products available -
Door coupling handle for switchgear 1 products available
Technical properties
Electric current
-
Rated current160 A
Architecture
-
Number of poles4
-
Control/operation elementDoor coupling rotary drive
Voltage
-
Rated insulation voltage Ui750 V
Power
-
Total power loss under IN86.40 W
-
Power loss per pole at In21.60 W
-
Rated operational power under 400 V AC AC1105,000 W
Safety
-
Ingress Protection (IP) classIP00
Fuse
-
Fuse sizeNH00
Dimensions
-
Height162 mm
-
Width184 mm
Cover, door
-
InterlockableYes
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet HFD416
Fuse comb. switch 4P - 160 A / T00
PDF -
Declaration of conformity
Declaration
Declaration of conformity International 2022-04-13
PDF941,41 kB
More documentation
