Fuse comb. switch 3P - 630 A / T3 HFD363
EAN
3250613130404
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Auxiliary contact block 2 products available -
Terminal cover 4 products available -
Switch operating shaft 1 products available -
Door coupling handle for switchgear 1 products available
Complete your system
Technical properties
Electric current
-
Rated current630 A
Architecture
-
Number of poles3
-
Control/operation elementDoor coupling rotary drive
Voltage
-
Rated insulation voltage Ui1,000 V
Power
-
Total power loss under IN366 W
-
Power loss per pole at In122 W
-
Rated operational power under 400 V AC AC1414,000 W
Safety
-
Ingress Protection (IP) classIP00
Fuse
-
Fuse sizeNH3
Dimensions
-
Height300 mm
-
Width364 mm
Cover, door
-
InterlockableYes
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet HFD363
Fuse comb. switch 3P - 630 A / T3
PDF -
Declaration of conformity
Declaration
Declaration of conformity International 2022-04-13
PDF941,41 kB
More documentation
