Fuse comb. switch 3P - 63 A / T000 HFD306
EAN
3250613130305
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Terminal cover 1 products available
Technical properties
Electric current
-
Rated current63 A
Architecture
-
Number of poles3
-
Control/operation elementDoor coupling rotary drive
Voltage
-
Rated insulation voltage Ui750 V
Power
-
Total power loss under IN25.20 W
-
Power loss per pole at In8.40 W
-
Rated operational power under 400 V AC AC141,000 W
Safety
-
Ingress Protection (IP) classIP00
Fuse
-
Fuse sizeNH000
Dimensions
-
Height118 mm
-
Width136 mm
Cover, door
-
InterlockableYes
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet HFD306
Fuse comb. switch 3P - 63 A / T000
PDF -
Declaration of conformity
Declaration
Declaration of conformity International 2022-04-13
PDF941,41 kB
More documentation
