    Hager The Hager GD mini‑enclosure, 2‑module wide, is a compact surface‑mounted housing for small 230 V circuits and controls. With 1 row/rail for up to 2 DIN modules and a 32 A rating, it suits MCBs or RCBOs. Class II insulation, IP30 and IK05 provide safe, robust indoor use. Pure white RAL9010 plastic, 160×55×82 mm. Supplied without door, lock, terminals or mounting plate. Ideal for tidy, space‑saving additions.
    EAN
    3250612846504
    Packaging
    10
    • GD distri­bu­tion board and accessories

    Mini-enclosure GD Surface 2-module IP30 Class II IK05 without door GD102T

    Add to a list
    Add to a list

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in

    Mini-enclosure GD Surface 2-module IP30 Class II IK05 without door

    GD102T

    • Accessories
    • Technical properties
    • Environmental value
    • Documentations
    • More products
    Download the data sheet

    Complete your system

    Optional accessories

    • Door/­op­er­ating panel 1 products available
    • Cover strip 2 products available

    Compatible products

    • Suitable with 2 products available

    Complete your system

    • Door/­op­er­ating panel
    • Cover strip
    • GP102T

      Door for mini-enclosure Gamma / GD, 2 Mod wide, White
      EUR 0.00  / *
    • JP015

      Cover strip, universal, 18M, RAL9010
      EUR 0.00  / *
    • JP011

      Cover strip, universal, RAL 9010
      EUR 0.00  / *

    Suitable with

    • EMERG2WA

      Emerg Test Kit Enclosed 2 NC Circuit (wired)
      EUR 0.00  / *
    • EMERG4WA

      Emerg Test Kit 2 NC Circuit (wired)
      EUR 0.00  / *

    Technical properties

    Voltage
    • Nominal voltage
      230 - 230 V
    Install­a­tion, mounting
    • Mounting on
      Surface mounting
    Elec­tric current
    • Rated current
      32 A
    Equip­ment
    • Number of rails
      1
    • Number of rows
      1
    • With lock
      No
    • Has neutral terminal block
      No
    • Has earthing terminal block
      No
    • Has mounting plate
      No
    Capa­city
    • Number of modules
      2
    Dimen­sions
    • Height
      160 mm
    • Width
      55 mm
    • Depth
      82 mm
    • Number of width units
      2
    Cover, door
    • Door/­cover is trans­parent
      No
    Mater­ials
    • Material
      Plastic
    • RAL code
      9010
    • Colour
      Pure white
    Safety
    • Protec­tion class
      Isol­a­tion class II
    • Impact resist­ance IK
      IK05
    • Ingress Protec­tion (IP) class
      IP30
    • Locking type
      Without lock
    • Glow wire test
      750 °C

    Environmental value

    We are committed to improve our environmental performance by reducing our carbon footprint. Learn More

    Certifications and documents

    PEP - ENCLOSURE SURFACE GAMMA 26 M (english)
    PDF
    25,39 MB

    Downloads

    • Product image

      Image GD102T | Hager Australia

      Product Image GD102T

    • Product datasheet

      Image Hager Product data sheet GD102T | Hager Australia

      Hager Product data sheet GD102T

      Mini-enclosure, GD, 2 module wide, protect. class IP30, without door

      PDF

    • Installation manual

      Image Installation manual International 2020-01-01 | Hager Australia

      Installation manual International 2020-01-01

      PDF
      2,01 MB

    • Declaration of conformity

      Image Declaration | Hager Australia

      Declaration

      Declaration of conformity International 2022-10-14

      PDF
      824,09 kB
      Image Declaration of conformity en-GB 2024-04-15 | Hager Australia

      Declaration of conformity en-GB 2024-04-15

      PDF
      174,16 kB
