Mini-enclosure, GD, 4 module wide, protect. class IP30,without door GD104T
EAN
3250612846511
Packaging
5
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Door/operating panel 1 products available -
Cover strip 2 products available
Technical properties
Voltage
-
Nominal voltage230 - 230 V
Installation, mounting
-
Mounting onSurface mounting
Electric current
-
Rated current40 A
Equipment
-
Number of rails1
-
Number of rows1
-
With lockNo
-
Has neutral terminal blockNo
-
Has earthing terminal blockNo
-
Has mounting plateNo
Capacity
-
Number of modules4
Dimensions
-
Height180 mm
-
Width110 mm
-
Depth82 mm
-
Number of width units4
Cover, door
-
Door/cover is transparentNo
Materials
-
MaterialPlastic
-
RAL code9010
-
ColourPure white
Safety
-
Protection classIsolation class II
-
Impact resistance IKIK05
-
Ingress Protection (IP) classIP30
-
Locking typeWithout lock
-
Glow wire test750 °C
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Installation manual
Installation manual International 2020-01-01
PDF2,01 MB -
Declaration of conformity
Declaration
Declaration of conformity International 2022-10-14
PDF824,09 kB
