slottet panel trunking HA7 80x40, light grey HA780040
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Spacer sleeve 2 products available -
Wire clamp slotted cable duct system 1 products available -
Draper hand riveter 3 products available -
Screw rosette 1 products available -
Shears for cutting trunking 1 products available
Complete your system
Technical properties
Dimensions
-
Height80 mm
-
Width40 mm
-
Length2000 mm
-
Slit width6 mm
-
Slot width6.50 mm
-
Inner cross-section2498 - 2498 mm²
Equipment
-
Cover in scope of deliveryYes
Materials
-
MaterialPC-ABS
-
ColourLight grey
-
RAL code7035
Functions
-
Is self-extinguishingYes
Standards
-
Flammability class according UL94V0
Safety
-
Fire resistance classM1
Architecture
-
FlexibleNo
Configuration
-
Side wallSlotted
Connectivity
-
Mounting typeScrew mounting
Installation, mounting
-
Mounting onMounting plate
Electric current
-
Is current leak stableYes
Environmental value
