The Hager Gamma surface-mounted enclosure (Israel version) delivers 54 modules over 3 rows/rails for residential and light commercial distribution. Rated 63A, it includes neutral and earth terminal blocks for clean, reliable wiring. Compact 500×355×103 mm plastic body in RAL9010, IK05 impact, IP30 protection, without door or lock. Ideal for space-efficient, compliant installations.

EAN

3250612846030

VPE

1 piece

gamma+ 13 and 18 enclosures

Enclosure Gamma Surface mounting 39M 3-row 63A IP30 IK05 Israel GD318M

Accessories
Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

product.page.accessories.title

Cover strip 2 product.page.accessories.products-available
Side/back panel 1 product.page.accessories.products-available
Accessories/spare parts for terminals 1 product.page.accessories.products-available
Accessories/spare parts for low-voltage switch technology 1 product.page.accessories.products-available

Technical characteristics

Mounting on

Surface mounting

Rated current IN

63 A

Number of rails

3
Number of rows

3
Number of section in width

1
Has neutral terminal block

Yes
Has earthing terminal block

Yes

Number of modules

54

Height

500 mm
Width

355 mm
Depth

103 mm
Number of width units

18

Number of cabinet doors

0
Number of locks

0

Material

Plastic
RAL code

9010
Colour

Pure white

Impact resistance IK

IK05
Ingress Protection (IP) class

IP30
Locking type

Without lock
Protection class with door

IP40

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
