The Hager on-delay voltage and phase control relay monitors 230-400 V networks (1P+N or 3P+N) to protect loads from phase faults and voltage anomalies. A single changeover contact with max 10 s off-delay enables controlled switching and reduces nuisance restarts after power return. Only 17.5 mm wide (87×65 mm), it saves panel space and is ideal for reliable motor and equipment protection on 50 Hz systems.
EAN
3250615600530
VPE
1 piece
RCCB 1P+N 40A 100mA AC Type S Selective 230V 2 Modules EUD100
catalog.lists.product_addition.login_popup.title
catalog.lists.product_addition.login_popup.descriptive_text
Technical characteristics
Capacity
-
Number of modules1
Frequency
-
Frequency50 - 50 Hz
Tripping
-
Max. permitted off-delay time10 s
Dimensions
-
Height87 mm
-
Width17.50 mm
-
Depth65 mm
Voltage
-
Rated operational voltage Ue230 - 400 V
