The Hager twilight switch, 1-channel, 1 module with wall-mounted cell, automates lighting by ambient light to save energy and improve comfort. For 230 V, 50-60 Hz circuits, it switches up to 10 A and includes a 60 s switch-on delay to prevent nuisance operation. DIN-rail mounting, screw terminals for 1.5-6 mm² conductors. Operates -5 to +45 °C. Supports wall/ceiling sensor extension. Compact: 83×17.8×65 mm.
EAN
3250617579308
VPE
1 piece
Multifunction meter LCD 0-9999 A 45-65 Hz 96x96 Flush/Surface IP51 EEN100
catalog.lists.product_addition.login_popup.title
catalog.lists.product_addition.login_popup.descriptive_text
product.page.accessories.title
product.page.accessories.associated-products
-
Brightness sensor 1 product.page.accessories.products-available
Technical characteristics
Frequency
-
Frequency50 - 60 Hz
Voltage
-
Rated operational voltage Ue230 - 230 V
Settings
-
Switch on delay time60 s
Use conditions
-
Operating temperature-5 - +45 °C
-
Storage/transport temperature-25 - +70 °C
Connection
-
Cross-section flexible conductor1.5 - 6 mm²
-
Cross-section rigid conductor1.5 - 6 mm²
Capacity
-
Number of modules1
Texts
-
Installation modeFor mounting on DIN rail, Extension sensor for wall and ceiling mounting
-
Type of connectionWith screw terminals
Electric current
-
Switching current10 A
-
Acceptable current rating AC110 A
Dimensions
-
Height83 mm
-
Width17.80 mm
-
Depth65 mm
Power supply
-
Supply voltage230 V +10%/-15%
Power
-
Power consumption (VA)0.30 VA
Lighting
-
Brightness measuring range5 - 2000 lx
