Cartridge N-PE Uc 260V In 20kA Imax 40kA Up 1.5kV SPB040N
EAN
3250615515353
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Capacity
-
Number of modules1
Voltage
-
Rated operational voltage Ue240 - 415 V
-
Continuous operating voltage Uc according to IEC 61643-1260 V
-
Voltage protection level Up L-PE/N-PE according to IEC 61643-111.5 kV
Electric current
-
Nominal discharge current In 8 - 20 µs L-N(PEN)/N-PE IEC 6164320 kA
-
Max. discharge (Imax) L-N(PEN)/ N-PE40 kA
Dimensions
-
Height52.4 mm
-
Width17.5 mm
-
Depth55.3 mm
Use conditions
-
Operating temperature-40 - 80 °C
Network configuration
-
Network typeTN, TT
Connection
-
Cross-section of input and output with screws, for flexible conductors1.5 - 25.0 mm²
-
Cross-section of input and output with screws, for massive conductors1.5 - 35.0 mm²
Standards
-
Requirement class IEC 61643T2
Frequency
-
Frequency50 - 60 Hz
Installation, mounting
-
Nominal tightening torque3 - 3 Nm
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More
Certifications and documents
Downloads
-
Product image
-
Declaration of conformity
Declaration of conformity for Lightning rod 8-15-40-65-100kA
Declaration of conformity International 2021-08-25
PDF305,83 kB
More documentation
