    Hager The Hager Golf small surface-mounted distributor is a 1-row, 18-module board with a transparent door for quick visual checks. Rated 63 A, Class II, IP40, IK07 for safe, robust use in residential or light commercial installations. Includes N and PE terminal blocks and quick-connect terminals for fast wiring. Pure white RAL9010 plastic, 252×390×99 mm, 1 rail, snap-on closure, no lock.
    EAN
    3250616466616
    Packaging
    1 Piece
    • golf enclos­ures

    Small distributor Golf surface 1-row IP40 18M QC-terminal N+PE transparent door VS118TTQ

    Add to a list
    Add to a list

    Login to create a product list

    You need to be logged into your myHager account to create product lists

    Create an account Sign in

    Small distributor Golf surface 1-row IP40 18M QC-terminal N+PE transparent door

    VS118TTQ

    • Accessories
    • Technical properties
    • Environmental value
    • Documentations
    • More products
    Download the data sheet

    Complete your system

    Optional accessories

    • Cover strip 2 products available
    • Cover­/in­fill panel/iden­ti­fic­a­tion strip 1 products available
    • Door/­op­er­ating panel 2 products available
    • Coax connector 1 products available
    • Quick­-re­lease fastener for housing covers 1 products available

    Complete your system

    • Cover strip
    • Cover­/in­fill panel/iden­ti­fic­a­tion strip
    • Door/­op­er­ating panel
    • Coax connector
    • Quick­-re­lease fastener for housing covers
    • JP015

      Cover strip, universal, 18M, RAL9010
      EUR 0.00  / *
    • JP011

      Cover strip, universal, RAL 9010
      EUR 0.00  / *
    • VZ788N

      Labeling strips, golf, adhesive, 396mm, surface, flush m. distributor, accessory, 10pcs
      EUR 0.00  / *
    • VZ607N

      Door, golf, white, accessory, for VF/VS118
      EUR 0.00  / *
    • VZ627N

      Door, golf, transparent, accessory, for VF/VS118
      EUR 0.00  / *
    • TN010S

      F type module complete
      EUR 0.00  / *
    • VZ862N

      Kit with 4 screws, Golf, for surface mount covers 04 to 72 M
      EUR 0.00  / *

    Technical properties

    Install­a­tion, mounting
    • Mounting on
      Surface mounting
    Elec­tric current
    • Rated current
      63 A
    Equip­ment
    • Number of rails
      1
    • Number of rows
      1
    • With lock
      No
    • Has neutral terminal block
      Yes
    • Has earthing terminal block
      Yes
    • Has mounting plate
      No
    Capa­city
    • Number of modules
      18
    Dimen­sions
    • Height
      252 mm
    • Width
      390 mm
    • Depth
      99 mm
    • Number of width units
      18
    Cover, door
    • Number of cabinet doors
      1
    • Number of locks
      0
    • Door/­cover is trans­parent
      Yes
    Mater­ials
    • Material
      Plastic
    • RAL code
      9010
    • Colour
      Pure white
    Safety
    • Protec­tion class
      Isol­a­tion class II
    • Impact resist­ance IK
      IK07
    • Ingress Protec­tion (IP) class
      IP40
    • Locking type
      Snap on lock, Without lock
    • Glow wire test
      650 °C

    Environmental value

    We are committed to improve our environmental performance by reducing our carbon footprint. Learn More

    RoHS conform Yes

    Certifications and documents

    REACH declaration VS118TTQ
    PDF
    RoHS report VS118TTQ
    PDF

    Downloads

    • Product image

      Image VS118TTQ | Hager Australia

      Product Image VS118TTQ

    • Product datasheet

      Image Hager Product data sheet VS118TTQ | Hager Australia

      Hager Product data sheet VS118TTQ

      Small distributor,golf,surface,1row,IP40,18M,QC-terminal,N+PE,transparent door

      PDF

    • Installation manual

      Image Installation manual International 2020-01-01 | Hager Australia

      Installation manual International 2020-01-01

      PDF
      3,50 MB

    • Declaration of conformity

      Image Declaration of conformity en-GB 2025-06-25 | Hager Australia

      Declaration of conformity en-GB 2025-06-25

      PDF
      487,74 kB
