MCB 2P 6kA D-16A 2M MDN216P

EAN
3250614353116
Packaging
6

You have to log in with your myHager profile to see prices and to order.

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in
Phase out product: please contact your electrical wholesaler for availability

Follow-up products :

NDN216A

MCB 2P 6kA D-16A 2M

MDN216P

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations

Complete your system

Optional accessories

  • See more (12)
    • Locking inter­locking func­tions 1 products available
    • Phase separ­a­tion func­tions 1 products available
    • Terminal cover 1 products available
    • Mech­anic accessories for low-­voltage compon­ents 1 products available
    • Under voltage coil 1 products available
    • Shunt release 2 products available

    Complete your system

    • Locking inter­locking func­tions
    • Phase separ­a­tion func­tions
    • Terminal cover
    • Mech­anic accessories for low-­voltage compon­ents
    • Under voltage coil
    • Shunt release
    • Auxil­i­aries contact block
    • AOB electronic TPN type A
    • AOB elec­tronic TPN type A
    • MZN175

      Padlockable locking kit for MCB, RCCB and RCBO
      EUR 0.00  / *
    • MZN121

      1 set of 3 inter-pole barriers for MCB
      EUR 0.00  / *
    • MZN120

      Terminal shield / screw shield for MCB
      EUR 0.00  / *
    • LZ060

      Heat dissipation insert
      EUR 0.00  / *
    • MZ206

      Under voltage release 230V AC
      EUR 0.00  / *
    • MZ204

      Shunt trip 24-48V AC 12-48V DC
      EUR 0.00  / *
    • MZ203

      Shunt trip 230-415V AC 110-130V DC
      EUR 0.00  / *
    • MZ202

      Alarm contact 1C+1O 6A 240V AC
      EUR 0.00  / *
    • MZ201

      Auxiliary contact 1C+1O 6A 240V AC
      EUR 0.00  / *
    • BE163T

      Earth leakage add-on-block 3P 63A 100mA A Class 1mod
      EUR 0.00  / *
    • BF163T

      Earth leakage add-on-block 3P 63A 300mA A Class 1mod
      EUR 0.00  / *
    • BD163T

      Earth leakage add-on-block 3P 63A 30mA A Class 1mod
      EUR 0.00  / *

    Technical properties

    Elec­tric current
    • Rated current
      16 A
    • Rated current -15°C
      19,75 A
    • Rated current -10°C
      19,37 A
    • Rated current -5°C
      18,98 A
    • Rated current at 0°C
      18,58 A
    • Rated current 5°C
      18,18 A
    • Rated current 10°C
      17,76 A
    • Rated current 15°C
      17,34 A
    • Rated current at 20°C
      16,90 A
    • Rated current 25°C
      16,46 A
    • Rated current 30°C
      16 A
    • Rated current 35°C
      15,53 A
    • Rated current at 40°C
      15,04 A
    • Rated current at 45°C
      14,54 A
    • Rated current at 50°C
      14,02 A
    • Rated current 55°C
      13,48 A
    • Rated current 60°C
      12,91 A
    • Rated current 65°C
      12,32 A
    • Rated current 70°C
      11,70 A
    Archi­tec­ture
    • Type of pole
      2P
    • Curve
      D
    Capa­city
    • Number of modules
      2
    Main elec­trical attrib­utes
    • Rated short-­cir­cuit breaking capa­city Icn AC according to IEC 60898-1
      6 kA
    Install­a­tion, mounting
    • Nominal tight­ening torque
      2,80 - 2,80 Nm
    • Type of bottom connec­tion for modular devices
      bicon­nect
    • Type of top connec­tion for modular devices
      Screw terminal
    • 360° mounting posi­tion possible
      Yes
    Voltage
    • Rated oper­a­tional voltage Ue
      415 - 415 V
    • Type voltage supply
      AC
    • Rated insu­la­tion voltage Ui
      500 V
    • Rated impulse with­stand voltage Uimp
      6000 V
    Safety
    • Ingress Protec­tion (IP) class
      IP20
    • Grid distance
      60 mm
    Use condi­tions
    • Degree of pollu­tion according to IEC 60664 / IEC 60947-2
      2
    Connectivity
    • Type of connec­tion
      Screw terminal
    • Top connec­tion align­ment for modular devices
      Aligned terminal
    • Down connec­tion align­ment for modular devices
      Aligned terminal
    Dimen­sions
    • Height
      84,60 mm
    • Width
      35 mm
    • Depth
      70 mm

    Environmental value

    We are committed to improve our environmental performance by reducing our carbon footprint. Learn More

    RoHS conform Yes

    Certifications and documents

    Hager REACH declaration MDN216P
    PDF
    Hager RoHS report MDN216P
    PDF

    Downloads

    • Product image

      Image MDN216P | Hager Australia

      Product Image MDN216P

    • Declaration of conformity

      Image UKCA Declaration of Conformity | Hager Australia

      UKCA Declaration of Conformity

      PDF
      753,40 kB
