The Hager Golf small surface-mounted 3-row distributor delivers reliable circuit distribution for residential and light commercial sites. Rated 400 V/63 A, it offers 54 modules over 3 rails, with N and PE terminal blocks and conduit inlets for fast wiring. The pure white RAL9010 plastic enclosure features a transparent single door, IP40/IK07, Class II insulation, snap-on closure. Size 500×390×99 mm.

EAN

3250616595293

VPE

1 piece

golf enclosures

Golf surface small distributor 1-row IP40 8M N+PE transparent door 63A VS318TJ

Accessories
Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

product.page.accessories.title

Cover/infill panel/identification strip 2 product.page.accessories.products-available
Lock system 1 product.page.accessories.products-available

Technical characteristics

Nominal voltage

400 - 400 V

Suitable for outdoor usage

No
Mounting on

Surface mounting

Rated current IN

63 A

Number of rails

3
Number of rows

3
Number of section in width

1
With lock

No
Has neutral terminal block

Yes
Has earthing terminal block

Yes
Has mounting plate

No

Number of modules

54

With conduit inlets

Yes

Height

500 mm
Width

390 mm
Depth

99 mm
Number of width units

18

Number of cabinet doors

1
Number of locks

0
Door/cover is transparent

Yes
Cabinet door type

Single door

Material

Plastic
RAL code

9010
Colour

Pure white
Ultraviolet-resistant

No

Protection class

Isolation class II
Impact resistance IK

IK07
Ingress Protection (IP) class

IP40
Locking type

Snap on lock, Without lock
Glow wire test

650 °C
Protection class with door

IP40

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
