The Hager 4-channel KNX Radio remote control delivers intuitive wireless control of lighting, blinds, and scenes. Operating at 868.30 MHz (Receiver Cat. 2), it offers up to 100 m outdoor range. Four buttons handle on/off, up/down, and up to 6 scenes. Battery included (6 V) with approx. 5-year life. Compact (83×46.5×15.8 mm), IP50, -10 to 45 °C, with factory reset for fast commissioning.
EAN
3250616014046
Packaging
1 Piece
Label Strips Kit NewVegaD 10 pcs 24-module width TU404
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Frequency
-
Frequency transmission868 - 868 MHz
-
Radio transmission frequency868.30 MHz
Voltage
-
Operating voltage6 - 6 V
Functions
-
Max. radio transmission range indoors30 m
-
Max. radio transmission range outdoors100 m
Connectivity
-
Radio protocolKNX Radio
-
Receiver category2
Controls and indicators
-
Number of buttons4
Safety
-
Ingress Protection (IP) classIP50
Use conditions
-
Operating temperature-10 - 45 °C
Dimensions
-
Height83 mm
-
Width46.5 mm
-
Depth15.80 mm
Equipment
-
With batteryYes
Battery
-
Battery life5 years
Texts
-
FunctionEasy additional functions: +6 scenes, on/off operating mode, 1 up/down button control, Reset function (to factory setting)
