Surge protection RJ45 for Ethernet and VoIP networks SPK900
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Installation, mounting
-
Mounting onDIN rail
Standards
-
Requirement class IEC 61643C1, C2, C3, D1, B2
Voltage
-
Continuous operating voltage Uc according to IEC 61643-13.30 V
-
Voltage protection level Up according to IEC 61643-10.10 kV
Electric current
-
Nominal discharge current In 8 - 20 µs C2 IEC 616430.91 kA
-
Max. discharge (Imax) L-N(PEN)/ N-PE10 kA
Dimensions
-
Height102 mm
-
Width25 mm
-
Depth63.5 mm
Use conditions
-
Operating temperature-40 - 70 °C
Equipment
-
With remote signalling contactNo
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
More documentation
Discover more of this product range
-
5
-
1
SPB065RCartridge L-N Uc 320V In 20kA Imax 65kA Up 1, 35kV -
2
SPV340SPD T2 2P pluggable 40kA photovoltaic -
3
SPB065NCartridge N-PE Uc 260V In 20kA Imax 65kA Up 1, 5kV -
4
SPA800Combined SPD T1+T2 3P Uc 350V Iimp 25kA In 25kA Up 1.5kV TCN with remote contact -
5
SPB040NCartridge N-PE Uc 260V In 20kA Imax 40kA Up 1.5kV
