The Hager flat angle, halogen‑free accessory for LF 30x57 mm trunking enables a neat 90° change of direction on the same plane. Moulded ABS in traffic white RAL9016 (H 30 mm x W 60 mm), IK07 impact resistant, operating -5 to 60°C. Delivers safe, low‑emission cable routing and a clean finish without overlap. Ideal for residential and commercial trunking installations.
EAN
4012740011976
Packaging
1 Piece
Internal corner halogen-free for LF trunking 30x57mm RAL9016 IK07 LF3006059016
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Dimensions
-
Height30 mm
-
Width60 mm
Accessories
-
Type of accessoryMoulded
Settings
-
Angle range90 - 90
Materials
-
MaterialAcrylonitrile-Butadiene-Styrene (ABS)
-
TreatmentUntreated
-
ColourTraffic white
-
RAL code9016
Safety
-
Impact resistance IKIK07
Standards
-
Suitable for functional integrity according to DIN4102-12No
Use conditions
-
Operating temperature-5 - 60 °C
Equipment
-
With protective filmNo
Configuration
-
OverlappingNo
-
With antibacterial treatmentNo
Installation, mounting
-
Mounting onThrough lid
Architecture
-
SymmetricalYes
