Earth terminal, 35mm² • KXB35E | Hager
Location Hager in the world

  • Better buildings. Better tomorrows.

    • Menu
    Account
    EAN
    3250613941963
    Packaging
    20

    Earth terminal, 35mm², screw connection KXB35E

    Complete your system

    Optional accessories

    • Labelling material 3 products available
    • End bracket for terminal block 1 products available

    Technical properties

    Elec­tric current
    • Rated current
      0
    Power
    • Total power loss under IN
      1 W
    Dimen­sions
    • Height
      51.50 mm
    • Width
      54 mm
    • Depth
      16 mm
    Connectivity
    • Type of connec­tion
      Screw terminal
    Mater­ials
    • Material
      Poly­amide (PA)
    Install­a­tion, mounting
    • Mounting on
      DIN rail
    Connec­tion
    • Cross-sec­tion flex­ible conductor
      35 mm² max.
    • Cross-sec­tion rigid conductor
      50 mm² max.

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    RoHS conform Yes

    Certifications and documents

    REACH declaration KXB35E
    PDF
    RoHS report KXB35E
    PDF

    Downloads

    More documentation
