Feed-through terminal-phase, 35mm², 400V/125A, screw connection KXA35L
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Labelling material 3 products available -
Endplate and partition plate 1 products available -
Component terminal block 2 products available
Compatible products
-
Referenced by 1 products available
Technical properties
Electric current
-
Rated current125 A
Dimensions
-
Height51.50 mm
-
Width58 mm
-
Depth16 mm
Installation, mounting
-
Mounting onDIN rail
Connection
-
Cross-section flexible conductor35 mm² max.
-
Cross-section rigid conductor50 mm² max.
Materials
-
ColourGrey
-
MaterialPolyamide (PA)
Connectivity
-
Type of connectionScrew terminal
