The Hager external box for 630-800 A LBS and 315-400 A FCS provides a robust indoor enclosure to house high-current switching and protection devices. Steel, varnished RAL7035 with 1.5 mm sidewalls, IK05 and Class I insulation. Compact 250×500×300 mm design saves panel space. Opaque door, no locks. Surface-mounted for quick installation in switchrooms, ensuring tidy, accessible assemblies.

EAN

3250613415556

VPE

1 piece

Accessories Load break switches

Cover sleeve 16x30 mm ABS Brown RAL8014 Overlapping Click-mount ATEHA JZA702

Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

Technical characteristics

Height

250 mm
Width

500 mm
Depth

300 mm
Thickness of sidewall

1.5 mm

Protection class

Isolation class I
Impact resistance IK

IK05

Mounting on

Surface mounting
Suitable for outdoor usage

No

Colour

Light grey
RAL code

7035
Treatment

Varnished
Material

Steel

Number of locks

0
Door/cover is transparent

No

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
