The Hager 40A 4NO contactor with 230V~50Hz coil controls residential and light commercial loads (AC-7a/AC-7b). Rated 40A AC1 and 25A AC3 up to 400V, with 4kV impulse withstand and Ui 440V. Compact 3-module DIN design (54 mm width). Durable: 100,000 mechanical/30,000 electrical ops. Conductor range 1.5-25 mm². Ideal for lighting, heating, and small motor switching. Operating temp -10 to 50°C.

EAN

3250612401284

VPE

4 pieces

Installation relays, contactors, load shedding and accessories

Contactor 63A 4P 4NO coil 230V~50Hz AC-7a/7b 3 modules ESC440

Accessories
Technical characteristics
catalog.pageproduct.title_sustainability.h2
Documentations
More products

product.page.accessories.title

Auxiliary device for distribution board devices 1 product.page.accessories.products-available

Technical characteristics

Type of contacts

4NO
Number of contacts

4
Cross-section flexible conductor

1.5 - 16 mm²
Cross-section rigid conductor

1.5 - 25 mm²

Rated current IN

40 A
Acceptable current rating AC1

40 A
Acceptable current rating AC3

25 A

Number of modules

3

Frequency

50 - 50 Hz

Rated impulse withstand voltage Uimp

4000 V
Rated insulation voltage Ui

440 V
Rated operational voltage Ue

400 - 400 V
Command voltage AC

230 - 230 V
Command voltage DC

0 - 0 V

Operating temperature

-10 - 50 °C
Storage/transport temperature

-40 - 80 °C

Category of use

AC-7a/AC-7b

Number of mechanical operations

100000
Electric endurance in number of cycles

30000

Power dissipation at IN

14.30 W
Inrush power absorbed

62.50 VA

Height

85 mm
Width

54 mm
Depth

60 mm

Number of NO contacts

4
Number of NC contacts

0
With switch for manual switch

No

Hum-free

No

Number of poles

4

catalog.pageproduct.title_sustainability.h2

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes

REACh-SVHC free Yes
