The Hager Override Contactor 25A 4NO 230V 50Hz delivers reliable switching for lighting and motor loads. Rated Ue 400V and AC-7a/AC-7b, it suits residential and light commercial use. Four NO poles in a compact 2-module width with manual override. Robust: Ui 440V, Uimp 4 kV, -10 to 50°C, 100k mechanical/30k electrical cycles. Accepts 1-6 mm² flexible and 1-10 mm² rigid conductors.

EAN

3250612400881

Packaging

Installation relays, contactors, load shedding and accessories

Empty module 24x22.5 Aluminium IP20 24 slots, 580 mm length ERC425

Accessories
Technical properties
Environmental value
Documentations
More products

Download the data sheet

Complete your system

Auxiliary device for distribution board devices 1 products available

Technical properties

Type of contacts

4NO
Number of contacts

4
Cross-section flexible conductor

1 - 6 mm²
Cross-section rigid conductor

1 - 10 mm²

Rated current IN

25 A

Number of modules

2

Frequency

50 - 50 Hz

Rated impulse withstand voltage Uimp

4000 V
Rated insulation voltage Ui

440 V
Rated operational voltage Ue

400 - 400 V
Command voltage AC

230 - 230 V
Command voltage DC

0 - 0 V

Operating temperature

-10 - 50 °C
Storage/transport temperature

-40 - 80 °C

Category of use

AC-7a/AC-7b

Number of mechanical operations

100000
Electric endurance in number of cycles

30000

Power dissipation at IN

7.50 W
Inrush power absorbed

21 VA

Height

83 mm
Width

35.75 mm
Depth

60 mm

Number of NO contacts

4
Number of NC contacts

0
With switch for manual switch

Yes

Nominal tightening torque

1.20 - 1.20 Nm

Number of poles

4

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

RoHS conform Yes
