Bar/Cable-through Current Transformer BG 213 50/5A 1,5VA Class 1 SRA00505

EAN
4049857063857
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Bar/Cable-through Current Transformer BG 213 50/5A 1,5VA Class 1

SRA00505

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • DIN rail adapter 1 products available

Complete your system

  • DIN rail adapter
  • SRZH01

    Current Transformer - DIN rail mounting Accessory for BG xx3
    0.00 €  / *

Technical properties

Specific iden­ti­ficaton attrib­utes for Protec­tion
  • Filter Type product
    Plug-in current trans­former
Func­tions
  • Accuracy class
    1
Power
  • Power
    1.50 VA
  • Total power loss under IN
    0.50 W
Dimen­sions
  • Diameter of opening
    20 mm
  • Height
    78 mm
  • Width
    60 mm
  • Depth
    30 mm
  • Height of opening
    20 mm
  • Width of opening
    20 mm
Connectivity
  • Type of connec­tion
    Screw terminal
Frequency
  • Frequency
    50 - 60 Hz
Voltage
  • Rated insu­la­tion voltage Ui
    3,000 V
Use condi­tions
  • Oper­ating temper­ature
    -40 - 40 °C
  • Stor­age/trans­port temper­ature
    -40 - 40 °C
Connec­tion
  • Cross-sec­tion flex­ible conductor
    1.5 - 6 mm²
  • Cross-sec­tion rigid conductor
    1.5 - 6 mm²
Safety
  • Ingress Protec­tion (IP) class
    IP10
Elec­tric current
  • Max. intensity of primary
    50 A
  • Max. intensity of secondary
    5 A
Install­a­tion, mounting
  • Mounting on
    DIN rail, Mounting plate

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

RoHS conform Yes
REACh-SVHC free Yes
Halogen free Yes

Certifications and documents

Hager REACH declaration SRA00505
PDF
Hager RoHS report SRA00505
PDF

Downloads

  • Product image

    Image SRA00505 | Hager

    Product Image SRA00505

  • Product datasheet

    Image Hager Product data sheet SRA00505 | Hager

    Hager Product data sheet SRA00505

    Bar/Cable-through Current Transformer BG 213 50/5A 1,5VA Class 1

    PDF

  • Declaration of conformity

    Image EU Declaration of Conformity | Hager

    EU Declaration of Conformity

    Declaration of conformity en-GB, de-DE 2023-12-11

    PDF
    581,43 kB
