3-pole, 63A Modular Switch SBN363

EAN
3250615510228
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

3-pole, 63A Modular Switch

SBN363

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
Download the data sheet

Complete your system

Optional accessories

  • Locking inter­locking func­tions 1 products available
  • Phase separ­a­tion func­tions 1 products available
  • Terminal cover 1 products available
  • Auxil­iary device for distri­bu­tion board devices 1 products available

Complete your system

  • Locking inter­locking func­tions
  • Phase separ­a­tion func­tions
  • Terminal cover
  • Auxil­iary device for distri­bu­tion board devices
  • MZN175

    Padlockable locking kit for MCB, RCCB and RCBO
    0.00 €  / *
  • MZN121

    1 set of 3 inter-pole barriers for MCB
    0.00 €  / *
  • MZN120

    Terminal shield / screw shield for MCB
    0.00 €  / *
  • ESC080

    Auxiliary contact 6A, 1NO+1NC
    0.00 €  / *

Technical properties

Archi­tec­ture
  • Number of poles
    3
  • Neutral posi­tion
    Without neutral
  • Type of pole
    3P
Elec­tric current
  • Rated current
    63 A
  • Accept­able current rating AC21 category A
    63 A
  • Accept­able current rating AC21 category B
    63 A
  • Accept­able current rating AC22 category A
    63 A
  • Accept­able current rating AC22 category B
    63 A
  • Rated short-­cir­cuit making capa­city Icm under 415 V AC according to IEC 60947-3
    1.33 kA
  • Rated short-­time with­stand current Icw 1s IEC 60947
    0.94 kA
  • Rated condi­tional short-­cir­cuit current Inc with fuse according to IEC/EN 60669-2-4
    6000A/80A gG parallel 32A gG
Install­a­tion, mounting
  • Nominal tight­ening torque
    2.80 - 2.80 Nm
Voltage
  • Rated oper­a­tional voltage Ue
    400 - 400 V
  • Type voltage supply
    AC
  • Rated insu­la­tion voltage Ui
    440 V
  • Rated impulse with­stand voltage Uimp
    6,000 V
Capa­city
  • Number of modules
    3
Safety
  • Ingress Protec­tion (IP) class
    IP20
Frequency
  • Frequency
    50 - 60 Hz
Dimen­sions
  • Height
    83 mm
  • Width
    52.50 mm
  • Depth
    68 mm
Equip­ment
  • Number of NO contacts
    3
  • Number of NC contacts
    0
Use condi­tions
  • Oper­ating temper­ature
    -20 - 70 °C
  • Stor­age/trans­port temper­ature
    -40 - 80 °C
Connec­tion
  • Cross-sec­tion flex­ible conductor
    2.5 - 16 mm²
  • Cross-sec­tion rigid conductor
    2.5 - 25 mm²
Endur­ance
  • Number of mech­an­ical oper­a­tions
    60,000
  • Elec­trical durab­ility at nominal load in AC21 in oper­ating cycles
    5,000
  • Elec­trical durab­ility at nominal load in AC22 in oper­ating cycles
    5,000
Power
  • Total power loss under IN
    6.90 W
  • Power loss per pole at In
    2.30 W
Connectivity
  • Top connec­tion align­ment for modular devices
    Aligned terminal

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

RoHS conform Yes
REACh-SVHC free Yes

Certifications and documents

Hager REACH declaration SBN363
PDF
Hager RoHS report SBN363
PDF
2-pole, 63A Modular Switch
PDF
2,89 MB

Downloads

  • Product image

    Image SBN363 | Hager

    Product Image SBN363

  • Product datasheet

    Image Hager Product data sheet SBN363 | Hager

    Hager Product data sheet SBN363

    3-pole, 63A Modular Switch

    PDF

  • Product licence

    Image Licence for NETHERLANDS | Hager

    Licence for NETHERLANDS

    Product licence International 2024-08-09

    PDF
    2,53 MB
    Image Licence for NETHERLANDS | Hager

    Licence for NETHERLANDS

    Product licence International 2024-08-09

    PDF
    2,23 MB

  • Declaration of conformity

    Image EU Declaration of Conformity | Hager

    EU Declaration of Conformity

    Declaration of conformity en-GB 2025-02-06

    PDF
    990,73 kB
