125A 8 Way IP65 Metal TPN Board JK108BD
EAN
5015652251620
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Distributor assembly for device surface mounting 1 products available -
Distributor assembly RCCB 5 products available -
Small distribution board 1 products available -
Accessories/spare parts for low-voltage switch technology 1 products available
Complete your system
Technical properties
Dimensions
-
Height800 mm
-
Width600 mm
-
Depth300 mm
Safety
-
Ingress Protection (IP) classIP65
-
Protection classIsolation class III
-
Locking typeKey lock, Quarter turn lock
-
Impact resistance IKIK05
Installation, mounting
-
Mounting onSurface mounting
-
Suitable for outdoor usageNo
Materials
-
ColourLight grey
-
RAL code7035
-
MaterialSteel
Cover, door
-
Number of cabinet doors1
-
Door/cover is transparentNo
Electric current
-
Rated current125 A
