FW flush encl. 3-rows 36 modules, IP30, classII, niche 507x315x115mm FWU31S
EAN
3250612739479
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Panel for distribution board 1 products available -
Lock system 8 products available -
Feed-through terminal block 1 products available -
Built-in field for telecommunications 1 products available -
Accessories/spare parts for terminals 2 products available -
See more 11 other products available
Complete your system
-
FZ450N
Lock, univers, triangular 7mm, with 1 key, for enclosure IP44/54
-
FZ451NLock, univers, square 7mm, with 1 key, for enclosure IP44/54
-
FZ501NLock, univers, double-bit 3mm, with 1 key, for enclosure IP54
-
FZ502NLock, univers, triangular closing 7mm, with 1 key, for enclosure IP54
-
FZ531NLock,univers, knob handle, cylinder Nr.1333, with 2 keys, for encl. IP44/IP54
-
FZ597NLock, univers, cylinder Nr.1242E, with 2 keys, for enclosure IP44/54
-
FZ598NDoor shield with handle, for enclosure univers IP44
-
FZ824NLock, univers, cylinder Nr.1242E with seal cover and 2 keys
Technical properties
Connection
-
Number of conduit inlets2
Installation, mounting
-
Suitable for outdoor usageNo
-
Mounting onFlush mounting, Hollow wall
Electric current
-
Rated current125 A
Equipment
-
Number of rails3
-
Number of rows3
-
Number of section in width1
-
With lockNo
-
Has neutral terminal blockYes
-
Has earthing terminal blockYes
-
Has mounting plateNo
Capacity
-
Number of modules36
Functions
-
With conduit inletsYes
Dimensions
-
Height553 mm
-
Width353 mm
-
Depth125 mm
-
Built-in height502 mm
-
Built-in width310 mm
-
Built-in depth112 mm
-
Number of width units12
Cover, door
-
Number of cabinet doors1
-
Type of handleHinged pattern handle
-
Door/cover is transparentNo
Materials
-
MaterialSteel
-
RAL code9010
-
ColourPure white
Safety
-
Protection classIsolation class II
-
Impact resistance IKIK09
-
Ingress Protection (IP) classIP30
-
Locking typeWithout lock
