IR motion detector comfort 1.1 m, S.1/B.3/B.7, polar white glossy 85341289
EAN
4011334373650
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Must-have accessories
Compatible products
-
Referenced by 18 products available
Referenced by
-
10128989Frame 2gang, S.1, p. white glossy
-
85421200Universal touch dimmer 1gang, electronics
-
85121200Relay insert, electronics
-
85320100Extension unit for motion det., electronics
-
10158982Frame 5gang, S.1, white glossy
-
10158989Frame 5gang, S.1, p. white glossy
-
10159909Frame 5gang, S.1, p. white, matt, plastic
-
13098989Frame l. cut-out, S.1, p. white glossy
-
10128982Frame 2gang, S.1, white glossy
-
10238919Frame 3gang hor., lab. field, S.1, p. white glossy
-
10129909Frame 2gang, S.1, p. white, matt, plastic
-
10148982Frame 4gang, S.1, white glossy
-
10148989Frame 4gang, S.1, p. white glossy
-
10149909Frame 4gang, S.1, p. white, matt, plastic
-
10128919Frame 2gang vert., lab. field, S.1, p. white glossy
-
10138919Frame 3gang vert., lab. field, S.1, p. white glossy
-
10228919Frame 2gang hor., lab. field, S.1, p. white glossy
-
10139909Frame 3gang, S.1, p. white, matt, plastic
Technical properties
Dimensions
-
Installation height1.10 - 1.10 m
-
Assembling height34 mm
Detection
-
Type of sensorMovement detector
-
Detection diameter on floor0 - 0 m
-
Detection angle adjustable45 - 90 °
Materials
-
ColourPolar white
-
Surface finishGlossy
-
TreatmentUntreated
-
MaterialThermoplastic
Reach distance
-
Max. transmission range frontally12 m
-
Max. transmission range sideways8 m
Lighting
-
Response brightness adjustable5 - 1,000 lx
Settings
-
Response brightness adjustableYes
Use conditions
-
Operating temperature-5 - 45 °C
Safety
-
Ingress Protection (IP) classIP20
Texts
-
FunctionWith memory function for presence simulation, Teach function for response brightness via button, With keylock, Party function for switching on for 2 hours
-
ProtectionWith dismantling protection
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet 85341289
IR motion detector comfort 1.1 m, S.1/B.3/B.7, polar white glossy
PDF -
Installation manual
Manual for 8534xx - IR motion detector comfort (EN, 2022-04)
Installation manual en-GB 2022-04-28
PDF1,89 MB -
Declaration of conformity
Declaration of Conformity
Declaration of conformity International 2021-02-15
PDF1,01 MB
Declaration of Conformity
Declaration of conformity International 2021-02-15
PDF1,01 MB
