Terminal,QuickConnect,neutral,22 connections KN22N
EAN
3250613849153
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Number of poles1 P
-
Type of pole1 P
Functions
-
Suitable for flexible coreYes
Main electrical features
-
Nominal voltage230 V
Electric current
-
Rated current63 A
Dimensions
-
Depth of installed product34 mm
-
Height of installed product33 mm
-
Width of installed product90 mm
Materials
-
Copper weight of the product0.021 kg
Connection
-
Conductor cross-section (flexible), with wire end sleeve1.5…25 mm²
-
Conductor cross-section (rigid)1.5…25 mm²
Settings
-
terminal typeN terminal
Safety
-
REACH conformNo
-
RoHS conformYes
-
Halogen freeNo
