Terminal,QuickConnect,earth,14 connections KN14E
EAN
3250613849030
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Number of poles1 P
-
Type of pole1 P
Functions
-
Suitable for flexible coreYes
Main electrical features
-
Nominal voltage230 V
Electric current
-
Rated current63 A
Dimensions
-
Depth of installed product34 mm
-
Height of installed product33 mm
-
Width of installed product60 mm
Materials
-
Copper weight of the product0.015 kg
Connection
-
Conductor cross-section (flexible), with wire end sleeve5…25 mm²
-
Conductor cross-section (rigid)1.5…25 mm²
Settings
-
terminal typePE terminal
Safety
-
REACH conformNo
-
RoHS conformYes
-
Halogen freeNo
Downloads
-
Product image
-
Instruction manual
Instruction manuals for KN14E
URL
Montageanleitung QC Einzelmodul
PDF361 KB -
Declaration of conformity
Declaration
PDF332 KB
Declaration
PDF217 KB
Declaration
PDF200 KB
Declaration
PDF100 KB -
RoHS report
REACH-declaration 2023-10-20 (english)
PDF33 KB
RoHS-declaration 2023-10-20 (english)
PDF33 KB
More documentation
