Moulded Case Circuit Breaker h3 x160 TM ADJ 3P3D 63A 25kA CTC

HHA063U

  • Main Switchgear

Moulded Case Circuit Breaker h3 x160 TM ADJ 3P3D 63A 25kA CTC HHA063U

EAN
3250613130756
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in
  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • Shunt release 4 products available
  • Under voltage coil 1 products available
  • Auxil­i­aries contact block 4 products available
  • Handle for power circuit breaker 2 products available
  • Locking inter­locking func­tions 1 products available
  • See more 8 other products available

Complete your system

  • Shunt release
  • Under voltage coil
  • Auxil­i­aries contact block
  • Handle for power circuit breaker
  • Locking inter­locking func­tions
  • Connec­tion Func­tions
  • Phase separ­a­tion func­tions
  • DIN rail adapter
  • Terminal cover
  • HXA001H

    Shunt trip 24V DC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA002H

    Shunt trip 48V DC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA004H

    Shunt trip 200-240V AC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA005H

    Shunt trip 380-450V AC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA014H

    Undervoltage release 200-240V AC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA021H

    Auxiliary contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA024H

    Alarm contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA025H

    Auxiliary low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA026H

    Alarm contact low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA030H

    Direct rotary handle x160

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA031H

    Extended rotary handle x160

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HXA039H

    Padlock (x160-P160-x250-P250-x630)

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA005H

    Collar terminal x160 Al 3P

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA013H

    Extended connection x160 4P collar

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA014H

    Spreader x160 3P collar

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA019H

    Interphase barrier x160 3/4P

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA033H

    DIN Rail adaptator x160 3P/4P

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA021H

    Terminal cover x160 3P long

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA023H

    Terminal cover x160 3P spreader

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HYA027H

    Terminal cover for collar terminal x160 3P

    EUR 0.00  / *
    Add to a list
    Add to a list

Technical properties

Elec­tric current
  • Rated current
    63 A
  • Rated ulti­mate short-­cir­cuit breaking capa­city Icu under 400 V AC IEC 60947-2
    25 kA
  • Rated ulti­mate short-­cir­cuit breaking capa­city Icu under 240 V AC IEC 60947-2
    35 kA
  • Rated service breaking capa­city Ics under 230 V AC according to IEC 60947-2
    25 kA
  • Rated service breaking capa­city Ics under 400 V AC according to IEC 60947-2
    20 kA
Archi­tec­ture
  • Number of poles
    3
Frequency
  • Frequency
    50 - 60 Hz
Voltage
  • Rated impulse with­stand voltage Uimp
    8000 V
  • Rated insu­la­tion voltage Ui
    690 V
  • Rated oper­a­tional voltage Ue
    220 - 415 V
Func­tions
  • Trip unit
    TM A/F
Power
  • Total power loss under IN
    30 W
Endur­ance
  • Elec­tric endur­ance in number of cycles
    1000
  • Number of mech­an­ical oper­a­tions
    4000
Safety
  • Ingress Protec­tion (IP) class
    IP4X
Connec­tion
  • Cross-sec­tion flex­ible conductor
    4 - 70 mm²
  • Cross-sec­tion rigid conductor
    4 - 95 mm²
Connectivity
  • Type of connec­tion
    Screw terminal
Settings
  • Thermal protec­tion knob setting xIN
    0.63, 0.8, 1
Dimen­sions
  • Height
    130 mm
  • Width
    75 mm
  • Depth
    68 mm

Environmental value

We are committed to improve our environmental performance by reducing our carbon footprint. Learn More

RoHS conform Yes
REACH conform Yes

Certifications and documents

REACH declaration HHA063U (english)
PDF
103,10 kB
RoHS declaration HHA063U (english)
PDF
103,59 kB

Downloads

  • Product image

    Image HHA063U  | Hager Australia

    Product Image HHA063U

  • Installation manual

    Image Installation manual International 2021-06-07  | Hager Australia

    Installation manual International 2021-06-07

    PDF
    8,51 MB
    Image Installation manual International 2021-06-07  | Hager Australia

    Installation manual International 2021-06-07

    PDF
    12,00 MB
  • Declaration of conformity

    Image EU Declaration of Conformity  | Hager Australia

    EU Declaration of Conformity

    Declaration of conformity en-GB 2025-03-20

    PDF
    430,96 kB
    Image UKCA Declaration of Conformity  | Hager Australia

    UKCA Declaration of Conformity

    Declaration of conformity en-GB 2025-03-20

    PDF
    435,49 kB
More documentation

Discover more of this product range

    5
  • 1
    HEC040H - Moulded Case Circuit Breaker h250 3P 70kA 40A LSI
    HEC040H
    Moulded Case Circuit Breaker h250 3P 70kA 40A LSI
  • 2
