Hager The Hager 3P 250 A T1 fuse combination switch delivers reliable switching and protection with NH1 fuses. With Ui 750 V and 164 kW AC-1 at 400 V, it suits main incomer or feeder isolation in industrial and commercial panels. A door-coupling rotary handle with door interlock enhances safety, while IP00 design is intended for installation inside enclosures. Robust 3-pole performance for dependable isolation and protection.
EAN
3250613130367
Packaging
1 Piece
Fuse combination switch 3P 250A NH1 door-coupling rotary drive IP00 Ui 750V HFD325
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Switch operating shaft 1 products available -
Door coupling handle for switchgear 1 products available
Complete your system
Technical properties
Electric current
-
Rated current250 A
Architecture
-
Number of poles3
-
Control/operation elementDoor coupling rotary drive
-
Type of pole3P
Voltage
-
Rated insulation voltage Ui750 V
Power
-
Total power loss under IN123,30 W
-
Power loss per pole at In41,10 W
-
Rated operational power under 400 V AC AC1164000 W
Safety
-
Ingress Protection (IP) classIP00
Fuse
-
Fuse sizeNH1
Dimensions
-
Height195 mm
-
Width234 mm
Cover, door
-
InterlockableYes
Environmental value
We are committed to improve our environmental performance by reducing our carbon footprint. Learn More
Certifications and documents
Downloads
-
Product image
-
Product datasheet
Hager Product data sheet HFD325
Fuse comb. switch 3P - 250 A / T1
PDF -
Enduserquickguide
Fuse combinaison switch 20 - 800 A
Enduserquickguide International 2017-06-19
PDF2,45 MB -
Declaration of conformity
Declaration
Declaration of conformity International 2022-04-13
PDF941,41 kB
