Fuse comb. switch 3P - 160 A / T00

HFD316

  • Main Switchgear

Fuse comb. switch 3P - 160 A / T00 HFD316

EAN
3250613130343
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in
  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • Door coup­ling handle for switchgear 1 products available
  • Switch oper­ating shaft 1 products available

Complete your system

  • Door coup­ling handle for switchgear
  • Switch oper­ating shaft
  • HZC002

    Black handle FCS- LBS 100-630A

    EUR 0.00  / *
    Add to a list
    Add to a list
  • HZC102

    Shaft extension 320 mm FCS-LBS 63-630A

    EUR 0.00  / *
    Add to a list
    Add to a list

Technical properties

Elec­tric current
  • Rated current
    160 A
Archi­tec­ture
  • Number of poles
    3
  • Control/­op­er­a­tion element
    Door coup­ling rotary drive
Voltage
  • Rated insu­la­tion voltage Ui
    750 V
Power
  • Total power loss under IN
    64,80 W
  • Power loss per pole at In
    21,60 W
  • Rated oper­a­tional power under 400 V AC AC1
    105000 W
Safety
  • Ingress Protec­tion (IP) class
    IP00
Fuse
  • Fuse size
    NH00
Dimen­sions
  • Height
    162 mm
  • Width
    148 mm
Cover, door
  • Inter­lock­able
    Yes

Environmental value

We are committed to improve our environmental performance by reducing our carbon footprint. Learn More

RoHS conform Yes
REACH conform Yes

Certifications and documents

REACH declaration HFD316 (english)
PDF
103,10 kB
RoHS declaration HFD316 (english)
PDF
103,59 kB

Downloads

  • Product image

    Image HFD316  | Hager Australia

    Product Image HFD316

  • Enduserquickguide

    Image Fuse combinaison switch 20 - 800 A  | Hager Australia

    Fuse combinaison switch 20 - 800 A

    Enduserquickguide International 2017-06-19

    PDF
    2,45 MB
  • Declaration of conformity

    Image Declaration  | Hager Australia

    Declaration

    Declaration of conformity International 2022-04-13

    PDF
    941,41 kB
