Moulded Case Circuit Breaker h3+ P250 TM ADJ 3P3D 100A 70kA FTC HET100DR

EAN
3250613170226
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Moulded Case Circuit Breaker h3+ P250 TM ADJ 3P3D 100A 70kA FTC

HET100DR

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • See more (30)
    • Terminal cover 4 products available
    • Shunt release 4 products available
    • Auxil­i­aries contact block 6 products available
    • Connec­tion Func­tions 3 products available
    • Handle with inter­lock for power breaker 1 products available
    • Handle for power circuit breaker 1 products available

    Complete your system

    • Terminal cover
    • Shunt release
    • Auxil­i­aries contact block
    • Connec­tion Func­tions
    • Handle with inter­lock for power breaker
    • Handle for power circuit breaker
    • Door coup­ling handle
    • Phase separ­a­tion func­tions
    • Auxil­i­aries inter­locking cable
    • Locking inter­locking func­tions
    • Motor oper­ator
    • Under voltage coil
    • HYT052H

      Earth plate for Spread terminal extension P250 3P
      EUR 0.00  / *
    • HYT050H

      Earth plate for Straight terminal extension P250 3P
      EUR 0.00  / *
    • HYT023H

      Terminal cover for Spread terminal extension P250 3P
      EUR 0.00  / *
    • HYT021H

      Terminal cover for Straight terminal extension P250 3P
      EUR 0.00  / *
    • HXA005H

      Shunt trip 380-450V AC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HXA001H

      Shunt trip 24V DC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HXA004H

      Shunt trip 200-240V AC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HXA002H

      Shunt trip 48V DC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HXA025H

      Auxiliary low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HXA027H

      Alarm contact NO-NC right side (x630/P630)
      EUR 0.00  / *
    • HXA028H

      Alarm contact-Low level NO-NC right side (x630/P630)
      EUR 0.00  / *
    • HXA021H

      Auxiliary contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HXA024H

      Alarm contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HXA026H

      Alarm contact low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *
    • HYT065H

      Cage terminal P250 cage version Cu/Al 3P 6x 6-35mm²
      EUR 0.00  / *
    • HYB011H

      Spreader (x/P250-P250) 3P
      EUR 0.00  / *
    • HYB031H

      Rear connection (x/P250-P250) - 3P
      EUR 0.00  / *
    • HXT032H

      Direct rotary handle P250 with interlocking
      EUR 0.00  / *
    • HXT030H

      Direct rotary handle for P250
      EUR 0.00  / *
    • HXT031H

      Rotary handle on door P250
      EUR 0.00  / *
    • HYT019H

      Interphase barrier for P250 3/4P
      EUR 0.00  / *
    • HXB069H

      Electrical interlock for Motor type B (x250-P250-h250-h400-h630-h800-h1000)
      EUR 0.00  / *
    • HXB068H

      Electrical interlock for Motor type A (x250-P250-h250)
      EUR 0.00  / *
    • HXA039H

      Padlock (x160-P160-x250-P250-x630)
      EUR 0.00  / *
    • HXB071H

      Interlock mechanical cable 1.5m (P160-x250-h250-h400-h630-h800-h1000)
      EUR 0.00  / *
    • HXB070H

      Interlock mechanical cable 1.0m (P160-x250-h250-h400-h630-h800-h1000)
      EUR 0.00  / *
    • HXT066H

      Mechanical interlocking front cover P250
      EUR 0.00  / *
    • HXT044H

      Motor Operator P250 230-240VAC without Auto-Reset
      EUR 0.00  / *
    • HXT042H

      Motor Operator P250 230-240VAC with Auto-Reset
      EUR 0.00  / *
    • HXA014H

      Undervoltage release 200-240V AC (x160-P160-x250-P250-x630-P630)
      EUR 0.00  / *

    Technical properties

    Elec­tric current
    • Rated current
      100 A
    • Rated ulti­mate short-­cir­cuit breaking capa­city Icu under 400 V AC IEC 60947-2
      70 kA
    • Rated ulti­mate short-­cir­cuit breaking capa­city Icu under 240 V AC IEC 60947-2
      85 kA
    • Rated service breaking capa­city Ics under 230 V AC according to IEC 60947-2
      85 kA
    • Rated service breaking capa­city Ics under 400 V AC according to IEC 60947-2
      50 kA
    • Rated current 10°C according to IEC 60947
      129,60 A
    • Rated current 15°C according to IEC 60947
      126,30 A
    • Rated current 20°C according to IEC 60947
      122,90 A
    • Rated current 25°C according to IEC 60947
      119,40 A
    • Rated current 30°C according to IEC 60947
      115,80 A
    • Rated current at 35°C according to IEC 60947
      112 A
    • Rated current at 40°C according to IEC 60947
      108,20 A
    • Rated current 45°C according to IEC 60947
      104,20 A
    • Rated current 50°C according to IEC 60947
      100 A
    • Rated current 55°C according to IEC 60947
      95,70 A
    • Rated current at 60°C according to IEC 60947
      91,10 A
    • Rated current 65°C according to IEC 60947
      86,30 A
    • Rated current 70°C according to IEC 60947
      81,20 A
    Archi­tec­ture
    • Number of poles
      3
    • Control/­op­er­a­tion element
      Toggle
    • Device construc­tion type
      Fixed built-in
    • Neutral posi­tion
      Without neutral
    Frequency
    • Frequency
      50 - 60 Hz
    Voltage
    • Rated impulse with­stand voltage Uimp
      8000 V
    • Rated insu­la­tion voltage Ui
      800 V
    • Rated oper­a­tional voltage Ue
      220 - 690 V
    Func­tions
    • Trip unit
      TM A/A
    Power
    • Total power loss under IN
      18 W
    Endur­ance
    • Elec­tric endur­ance in number of cycles
      10000
    • Number of mech­an­ical oper­a­tions
      40000
    Safety
    • Ingress Protec­tion (IP) class
      IP4X
    Connec­tion
    • Cross-sec­tion flex­ible conductor
      35 - 150 mm²
    • Cross-sec­tion rigid conductor
      35 - 185 mm²
    Cover, door
    • Inter­lock­able
      Yes
    Settings
    • Thermal protec­tion knob setting xIN
      0.63, 0.8, 1
    Cable
    • Cable material
      Copper, Aluminium
    Compat­ib­ility
    • Compat­ible with RDC AOB
      No
    • Suit­able for DIN Rail
      No
    • Suit­able for distri­bu­tion board
      Yes
    Dimen­sions
    • Height
      165 mm
    • Width
      105 mm
    • Depth
      97 mm
    Elec­trical protec­tion
    • Instant­an­eous protec­tion (li): dial setting coef­fi­cient
      6, 8, 10, 13
    Install­a­tion, mounting
    • Mount­ing-/­Con­nec­tion Posi­tion
      Front
    • Nominal tight­ening torque
      12 - 12 Nm

    Environmental value

    We are committed to improve our environmental performance by reducing our carbon footprint. Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    Moulded Case Circuit Breaker h3 x160 TM ADJ 3P3D 100A 18kA CTC
    PDF
    14,81 MB
    Hager REACH declaration HET100DR
    PDF
    Hager RoHS report HET100DR
    PDF

    Downloads

    • Product image

      Image HET100DR | Hager Australia

      Product Image HET100DR

    • Product datasheet

      Image Hager Product data sheet HET100DR | Hager Australia

      Hager Product data sheet HET100DR

      Moulded Case Circuit Breaker h3+ P250 TM ADJ 3P3D 100A 70kA FTC

      PDF

    • Installation manual

      Image Manual for moulded case circuit breaker h3+ P250 (Date: 2020-03) | Hager Australia

      Manual for moulded case circuit breaker h3+ P250 (Date: 2020-03)

      Installation manual International 2015-11-02

      PDF
      4,67 MB

    • Brochure

      Image Hager h3+ MCCB | Hager Australia

      Hager h3+ MCCB

      PDF
      8,80 MB

    • STEP files

      Image CAD file for MCCB 250A 3P | Hager Australia

      CAD file for MCCB 250A 3P

      STEP files International 2023-11-24

      STP
      640,83 kB

    • Handbook

      Image Technical catalogue | Hager Australia

      Technical catalogue

      h3+ Moulded Case Circuit breakers up to 630A

      PDF
      48,86 MB

    • Declaration of conformity

      Image Declaration | Hager Australia

      Declaration

      Declaration of conformity International 2022-04-25

      PDF
      349,41 kB
      Image Declaration | Hager Australia

      Declaration

      Declaration of conformity International 2022-04-25

      PDF
      461,97 kB
