1 channel digital time switch weekly cycle EGN103
EAN
3250618502435
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
EGN103 is not Bluetooth compatible as supplied, the optional accessory EGN003 Programming key is required.
Technical properties
Functions
-
With GPSNo
-
hour programYes
Configuration
-
Number of modules2
Connectivity
-
Connection modeRadio
Main electrical features
-
Rated operational voltage Ue230 V AC
-
Nominal voltage230 V
-
Type of supply voltageAC
-
Frequency50/60 Hz
Electric current
-
Switching current at 250 V~16 A
Dimensions
-
Depth of installed product61.6 mm
-
Height of installed product90 mm
-
Width of installed product35.8 mm
Frequency
-
Frequency range50…60 Hz
Power
-
Power consumed0.39 VA
-
Power consumption (operation)350 mW
Measurement
-
Running accuracy± 1.5 s/day
Battery
-
Battery / storage batterywith battery type: Lithium 1/2 AA
Fluorescent bulbs control
-
Fluorescent lampsmax. 1000 VA
-
Max. power with fluorescent parallel lamps400 W
-
Max. power fluo. duo lamp comp. series1000 W
-
Compact fluorescent lamps400 W
-
Fluorescent lamps parallel compensated400 W
-
Max. load fluorescent lamp400 W
Incandescent bulbs control
-
Max. power with incandescent lamps2300 W
-
230 V incandescent lamps and halogen lamps2300 W
Installation, mounting
-
Tightening torque1,2Nm
Connection
-
Connection cross-sect. flexible conductor1 / 6mm²
-
Connection cross-sect. rigid cable1,5 / 10mm²
-
Number of contacts1
-
Type of contacts1 changeover
-
Type of connectionwith screw terminal
-
Contactwith failsafe break contact (NC contact)
-
Type of connectionwith screw
Settings
-
Number of program steps56
-
Shortest switching time1 mn
-
ProgrammingProgramming possible without mains voltage
-
Annual programNo
-
Astro programNo
-
Daily programYes
-
Timewith automatic summer/winter time change-over
-
Weekly programYes
Scope of delivery
-
Memory card includedNo
Equipment
-
Type of programmable thermostatDigital
-
Number of channels1
-
Number of switching times for on/off56
-
Supply failure reserve5 years
-
Summer-/winter switchoverYes
-
With cyclic programNo
-
With holidays programNo
-
With Impulse programNo
-
With preset programmNo
-
With random programNo
Use
-
Local operation/hand operationYes
Safety
-
REACH conformNo
-
RoHS conformYes
-
Halogen freeNo
Use conditions
-
Degree of pollution according to IEC 60664 / IEC 60947-22
-
Working accuracy± 1,5 s / 24H
-
Relative humidity95 %
Identification
-
Device familyEG
