Line coupler, KNX TYF130
EAN
3250617577359
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Bus systemEIB
Functions
-
Easy link functionscan be used as line amplifier
Configuration
-
Number of modules2
Controls and indicators
-
Button / push-buttonwith programming button and red programming LED
Voltage
-
Operating voltage over bus21…32 V DC
-
System supply voltage30V DC via bus
Dimensions
-
Width of rail mounted device (RMD)2 modules
Power
-
Total power loss under IN0.5 W
LED control
-
LEDwith 2 yellow data traffic LEDs for higher and lower ranking line ; With green operation LED, red programming LED and red diagnosis LED
Connection
-
Type of connection to the busTG008 connector
-
Bus coupling unitwith integral bus coupling unit
-
Type of connectionline connection via connecting terminal
-
Bus connectionbus connection via connecting terminal
Settings
-
Supported configuration modessystem, easy
Safety
-
REACH conformYes
-
RoHS conformYes
-
Halogen freeYes
Use conditions
-
Operating temperature-5…45 °C
Identification
-
Main design lineKNX
