Insulated busbar 1P 80A fork 16mm² 12M KDN180A
EAN
3250613740986
Packaging
100 PCEs
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Number of poles1 P
-
Type of pole1 P
Compatibility
-
Intended for the compatible referencesModular devices
Main electrical features
-
Rated operational voltage Ue415 V
Voltage
-
Max operating voltage230 V
Electric current
-
Rated current80 A
Dimensions
-
Length210 mm
-
Pitch17.8 mm
Installation, mounting
-
Suitable to a device with an auxiliaryNo
Connection
-
Connection cross-sect. rigid cable16mm²
-
Suitable for product with neutral busbarNo
-
Connector typebusbar fork
-
Type of connectionwith screw / quick connect
Equipment
-
Number of appliances to build in12
Safety
-
Halogen freeNo
Use conditions
-
InsulatedYes
Downloads
-
Product image
-
ProductECDeclaration
Declaration
PDF342 KB -
ProductEnvironmentProfile
Product environmental profile for KDN180A
PDF429 KB -
ProductROHS
RoHS declaration KDN180A (english)
PDF103 KB
