Bell transformer 16VA 230V 8-12V

ST305

  • Modular devices

Bell transformer 16VA 230V 8-12V ST305

EAN
3250615703057
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in
  • Technical properties
  • Environmental value
  • More products
Download the data sheet

Technical properties

Voltage
  • Output voltage
    8 - 12 V
  • Rated oper­a­tional voltage Ue
    230 - 230 V
  • Output voltage 2
    12 V
  • Rated insu­la­tion voltage Ui
    4,000 V
Capa­city
  • Number of modules
    3
Power
  • Power consump­tion VA
    16 VA
  • Power
    16 VA
  • Power absorbed
    16 W
Dimen­sions
  • Height
    111 mm
  • Width
    54 mm
  • Depth
    65 mm
  • Length
    64 mm
Safety
  • Ingress Protec­tion (IP) class
    IP20
  • Temper­ature protec­tion
    Yes
Equip­ment
  • Is short-­cir­cuit protected
    Yes
  • On/off switch
    No
Use condi­tions
  • Oper­ating temper­ature
    -20 - 35 °C
Connec­tion
  • Cross-sec­tion flex­ible conductor
    4 mm²
  • Cross-sec­tion rigid conductor
    6 mm²
Frequency
  • Frequency
    50 - 50 Hz
Elec­tric current
  • Intensity output 1
    2 A
  • Intensity output 2
    1.33 A
  • Max. intensity of secondary
    2 A
Install­a­tion, mounting
  • Mounting on
    DIN rail
  • Nominal tight­ening torque
    1.20 - 1.20 Nm
Internal use only
  • Number of half modules of 17,5 mm
    6
Compat­ib­ility
  • Suit­able for DIN Rail
    Yes

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

Certifications and documents

REACH declaration ST305 (english)
PDF
103,10 kB
RoHS declaration ST305 (english)
PDF
103,59 kB
