JK108 48 Module Side DIN Box Glazed JK108BDFG

EAN
5015652257998
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

JK108 48 Module Side DIN Box Glazed

JK108BDFG

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • Small distri­bu­tion board 1 products available
  • Trans­ition cover section for install­a­tion duct 2 products available

Complete your system

  • Small distri­bu­tion board
  • Trans­ition cover section for install­a­tion duct
  • JK116EG

    JK1 16 Module DIN Rail Box Glazed
    0.00 €  / *
  • JK06TK

    Trunking Kit for TPN 6"
    0.00 €  / *
  • JK04TK

    Trunking Kit for TPN 4"
    0.00 €  / *

Technical properties

Install­a­tion, mounting
  • Suit­able for outdoor usage
    No
  • Mounting on
    Surface mounting
Elec­tric current
  • Rated current
    125 A
Equip­ment
  • Number of rows
    3
  • With lock
    Yes
  • Has neutral terminal block
    Yes
  • Has earthing terminal block
    Yes
Capa­city
  • Number of modules
    48
Dimen­sions
  • Height
    625 mm
  • Width
    465 mm
  • Depth
    132.50 mm
  • Number of width units
    48
Cover, door
  • Number of cabinet doors
    1
  • Door/­cover is trans­parent
    Yes
Mater­ials
  • Material
    Steel
  • RAL code
    7035
  • Colour
    Light grey
Safety
  • Protec­tion class
    Isol­a­tion class III
  • Impact resist­ance IK
    IK05
  • Ingress Protec­tion (IP) class
    IP3X
  • Locking type
    Key lock, Quarter turn lock

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

RoHS conform Yes
REACh-SVHC free Yes

Certifications and documents

Hager REACH declaration JK108BDFG
PDF
Hager RoHS report JK108BDFG
PDF

Downloads

  • Product image

    Image JK108BDFG | Hager

    Product Image JK108BDFG

  • Product datasheet

    Image Hager Product data sheet JK108BDFG | Hager

    Hager Product data sheet JK108BDFG

    JK108 48 Module Side DIN Box Glazed

    PDF

  • BIM Revit objects

    Image Range : Type B TP&N Distribution Boards. Switchboard IP3X with DIN rail system. English - Hosted family - REVIT Family 2020 - V2022 | Hager

    Range : Type B TP&N Distribution Boards. Switchboard IP3X with DIN rail system. English - Hosted family - REVIT Family 2020 - V2022

    BIM Revit objects en-GB 2024-03-22

    RFA
    1,28 MB
    Image Range : Type B TP&N Distribution Boards. Switchboard IP3X with DIN rail system. English - Non hosted family - REVIT Family 2020 - V2022 | Hager

    Range : Type B TP&N Distribution Boards. Switchboard IP3X with DIN rail system. English - Non hosted family - REVIT Family 2020 - V2022

    BIM Revit objects en-GB 2024-03-22

    RFA
    1,26 MB
    Image Range Typ.B TP&N 125A Side DIN Enclosures -Revit Family 2020 hosted-V2021 | Hager

    Range Typ.B TP&N 125A Side DIN Enclosures -Revit Family 2020 hosted-V2021

    BIM Revit objects en-GB 2020-01-01

    RFA
    1,27 MB
    Image Range Typ.B TP&N 125A Side DIN Enclosures -Revit Family 2020 no hosted-V2021 | Hager

    Range Typ.B TP&N 125A Side DIN Enclosures -Revit Family 2020 no hosted-V2021

    BIM Revit objects en-GB 2020-01-01

    RFA
    1,26 MB

  • Declaration of conformity

    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2021-09-29

    PDF
    276,98 kB
    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2021-09-29

    PDF
    269,32 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    302,50 kB
    Image Declaration of conformity International 2023-12-20 | Hager

    Declaration of conformity International 2023-12-20

    PDF
    296,11 kB
More documentation

Discover more of this product range

    5
  • 1
    JK11004RMD - 100A 100mA 4 Pole Time Delay RCCB Kit
    JK11004RMD
    100A 100mA 4 Pole Time Delay RCCB Kit
  • 2
    JK11004RM - 100A 100mA 4 Pole RCCB Incomer Kit
    JK11004RM
    100A 100mA 4 Pole RCCB Incomer Kit
  • 3
    JK11004RL - 100A 300mA 4 Pole RCCB Incomer Kit
    JK11004RL
    100A 300mA 4 Pole RCCB Incomer Kit
  • 4
    JK11004RLD - 100A 300mA 4 Pole Time Delay RCCB Kit
    JK11004RLD
    100A 300mA 4 Pole Time Delay RCCB Kit
  • 5
    JK11004RH - 100A 30mA 4 Pole RCCB Incomer Kit
    JK11004RH
    100A 30mA 4 Pole RCCB Incomer Kit
