Load Break Switch Disconnector h3+ P630 4P 630A FTC HCW631AR

EAN
3250613198763
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

Load Break Switch Disconnector h3+ P630 4P 630A FTC

HCW631AR

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • See more (42)
    • Under voltage coil 8 products available
    • Auxil­i­aries inter­locking cable 2 products available
    • Shunt release 5 products available
    • Locking inter­locking func­tions 3 products available
    • Auxil­i­aries contact block 4 products available
    • Connec­tion Func­tions 6 products available

    Complete your system

    • Under voltage coil
    • Auxil­i­aries inter­locking cable
    • Shunt release
    • Locking inter­locking func­tions
    • Auxil­i­aries contact block
    • Connec­tion Func­tions
    • Terminal cover
    • Mech­anic accessories for low-voltage compon­ents
    • Phase separ­a­tion func­tions
    • Handle for power circuit breaker
    • Chassis power breaker
    • Oper­ating shaft for power breaker
    • Handle with inter­lock for power breaker
    • HXA051H

      UVR delayed 24V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA015H

      Undervoltage release 380-450V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA014H

      Undervoltage release 200-240V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA055H

      UVR delayed 380-450V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA054H

      UVR delayed 220-240V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA011H

      Undervoltage release 24V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA053H

      UVR delayed 110-120V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA013H

      Undervoltage release 100-120V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXD068H

      Electrical interlock for Motor type A (h400-h630-x630-P630-h800-h1000)
      0.00 €  / *
    • HXB069H

      Electrical interlock for Motor type B (x250-P250-h250-h400-h630-h800-h1000)
      0.00 €  / *
    • HXA003H

      Shunt trip 100-120V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA005H

      Shunt trip 380-450V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA002H

      Shunt trip 48V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA001H

      Shunt trip 24V DC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA004H

      Shunt trip 200-240V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA039H

      Padlock (x160-P160-x250-P250-x630)
      0.00 €  / *
    • HXB070H

      Interlock mechanical cable 1.0m (P160-x250-h250-h400-h630-h800-h1000)
      0.00 €  / *
    • HXB071H

      Interlock mechanical cable 1.5m (P160-x250-h250-h400-h630-h800-h1000)
      0.00 €  / *
    • HXA026H

      Alarm contact low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA021H

      Auxiliary contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA024H

      Alarm contact 1NO+1NC 250V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HXA025H

      Auxiliary low level 1NO+1NC 125V AC (x160-P160-x250-P250-x630-P630)
      0.00 €  / *
    • HYW328H

      L connection terminal Plug-in (x630/P630) 1P
      0.00 €  / *
    • HYW015H

      Spread terminal extension x630/P630 4P (up to 630A)
      0.00 €  / *
    • HYW013H

      Straight terminal extension x630/P630 4P (up to 630A)
      0.00 €  / *
    • HYW008H

      Cage terminal x630/P630 Cu/Al 4P 2x 35-300mm²
      0.00 €  / *
    • HYW002H

      Cage terminal x630/P630 Cu/Al 4P 1x 35-300mm²
      0.00 €  / *
    • HYD034H

      Rear connection h/x/P 4P 630A
      0.00 €  / *
    • HYW026H

      Terminal cover for Rear & Plug-in connection x630/P630 4P
      0.00 €  / *
    • HYW024H

      Terminal cover for Spread terminal extension x630/P630 4P
      0.00 €  / *
    • HYW022H

      Terminal cover for Straight terminal extension x630/P630 4P
      0.00 €  / *
    • HYW256H

      Safety trip (x630/P630)
      0.00 €  / *
    • HXS920H

      Shaft guide for handle S1&S2 (P160-P250-x630-P630)
      0.00 €  / *
    • HYW019H

      Interphase barrier for x630/P630 3/4P
      0.00 €  / *
    • HXW031H

      Rotary grey handle on door x/P630
      0.00 €  / *
    • HXW030H

      Direct rotary handle for x630/P630
      0.00 €  / *
    • HYW331H

      Draw-out base 4P x630/P630
      0.00 €  / *
    • HYW201H

      Plug-in base for x630/P630 4P
      0.00 €  / *
    • HXW912H

      Shaft 14x14mm 200mm (10x10mm)
      0.00 €  / *
    • HXW913H

      Shaft 14x14mm 320mm (10x10mm)
      0.00 €  / *
    • HXW915H

      Shaft 14x14mm 500mm (10x10mm)
      0.00 €  / *
    • HXW032H

      Direct rotary handle for x630/P630, with door lock
      0.00 €  / *

    Technical properties

    Elec­tric current
    • Rated current
      630 A
    • Rated short-­time with­stand current Icw IEC 60947
      7.60 kA
    Archi­tec­ture
    • Number of poles
      4
    • Control/­op­er­a­tion element
      Toggle
    Voltage
    • Rated insu­la­tion voltage Ui
      800 V
    • Rated impulse with­stand voltage Uimp
      8,000 V
    Frequency
    • Frequency
      50 - 60 Hz
    Func­tions
    • Trip unit
      Switch

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    PEP document en-GB 2024-06-11
    PDF
    432,93 kB
    REACH declaration HCW631AR
    PDF
    RoHS report HCW631AR
    PDF

    Downloads

    • Product image

      Image HCW631AR | Hager

      Product Image HCW631AR

    • Product datasheet

      Image Hager Product data sheet HCW631AR | Hager

      Hager Product data sheet HCW631AR

      Load Break Switch Disconnector h3+ P630 4P 630A FTC

      PDF

    • Instruction manual

      Image Instruction manual International 2025-01-21 | Hager

      Instruction manual International 2025-01-21

      PDF
      10,29 MB
