Load break switch visible break. 3P 160A

HAE316

  • Modular devices
  • Switching and protective devices

Load break switch visible break. 3P 160A HAE316

EAN
3250613140328
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Add to a list
Add to a list

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in
  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
  • More products
Download the data sheet

Complete your system

Optional accessories

  • Door coup­ling handle for switchgear 1 products available
  • Switch oper­ating shaft 3 products available
  • Auxil­iary contact block 2 products available
  • Terminal cover 1 products available

Complete your system

  • Door coup­ling handle for switchgear
  • Switch oper­ating shaft
  • Auxil­iary contact block
  • Terminal cover
  • HZC014

    Grey handle LBS 100-160A
    0.00 €  / *
    Add to a list
    Add to a list
  • HZC114

    Shaft extension N°6 150mm LBS 100-160A
    0.00 €  / *
    Add to a list
    Add to a list
  • HZC115

    Shaft extension N°6 200mm LBS 100-160A
    0.00 €  / *
    Add to a list
    Add to a list
  • HZC116

    Shaft extension N°6 320mm LBS 100-160A
    0.00 €  / *
    Add to a list
    Add to a list
  • HZC311

    Auxiliary contact 1C+1O LBS 20-160A
    0.00 €  / *
    Add to a list
    Add to a list
  • HZC312

    Auxiliary contact 2C LBS 20-160A
    0.00 €  / *
    Add to a list
    Add to a list
  • HZC217

    Terminal shrouds 3P LBS 100-160A
    0.00 €  / *
    Add to a list
    Add to a list

Technical properties

Elec­tric current
  • Rated current
    160 A
  • Accept­able current rating AC21
    160 A
  • Accept­able current rating AC21 category B
    160 A
  • Accept­able current rating AC22 category B
    160 A
  • Accept­able current rating AC23 category A
    125 A
  • Accept­able current rating AC23 category B
    160 A
  • Rated short-­cir­cuit making capa­city Icm under 415 V AC according to IEC 60947-3
    7 kA
  • Rated short-­time with­stand current Icw 1s IEC 60947
    4 kA
  • Rated short-­time with­stand current Icw IEC 60947
    4 kA
Connec­tion
  • Cross-sec­tion rigid conductor
    70 mm²
  • Cross-sec­tion flex­ible conductor
    70 mm²
Voltage
  • Rated insu­la­tion voltage Ui
    800 V
  • Rated impulse with­stand voltage Uimp
    8,000 V
  • Rated oper­a­tional voltage Ue
    380 - 415 V
Power
  • Power loss per pole at In
    7.50 W
  • Total power loss under IN
    22.50 W
  • Rated oper­a­tional power under 400 V AC AC1
    105,000 W
  • Rated oper­a­tional power under 400 V AC AC23
    56,000 W
Equip­ment
  • Motor drive optional
    No
  • Number of auxil­iary contacts as change-over contact
    0
  • Number of auxil­iary contacts as normally closed contact
    0
  • Number of auxil­iary contacts as normally open contact
    0
Use condi­tions
  • Oper­ating temper­ature
    -20 - 70 °C
Cover, door
  • Inter­lock­able
    Yes
Safety
  • Ingress Protec­tion (IP) class
    IP20
Archi­tec­ture
  • Type of pole
    3P
  • Number of poles
    3
  • Control/­op­er­a­tion element
    Short rotary handle
Frequency
  • Frequency
    50 - 60 Hz
Func­tions
  • Is reversing switch
    No
  • Version as emer­gency stop install­a­tion
    No
  • Version as main switch
    Yes
  • Version as main­ten­ance/ser­vice switch
    Yes
  • Version as safety switch
    Yes
  • Version as switch discon­nector compact
    Yes
Capa­city
  • Number of modules
    6.22
Install­a­tion, mounting
  • Nominal tight­ening torque
    4 - 4.4 Nm
Connectivity
  • Type of connec­tion
    Screw terminal
Dimen­sions
  • Height
    84 mm
  • Width
    109 mm
  • Depth
    132 mm

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

RoHS conform Yes
REACH conform Yes

Certifications and documents

REACH declaration HAE316 (english)
PDF
103,10 kB
RoHS declaration HAE316 (english)
PDF
103,59 kB

Downloads

  • Product image

    Image HAE316 | Hager

    Product Image HAE316

  • Declaration of conformity

    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2022-04-13

    PDF
    835,39 kB
    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2022-09-07

    PDF
    635,00 kB
More documentation

Discover more of this product range

    5
  • 1
    HA307 - Load break switch 3P 160A
    HA307
    Load break switch 3P 160A
  • 2
    HA308 - Load break switch 3P 200A
    HA308
    Load break switch 3P 200A
  • 3
    HA351 - Load break switch 3P 125A
    HA351
    Load break switch 3P 125A
  • 4
    HA352 - Load break switch 3P 160A
    HA352
    Load break switch 3P 160A
  • 5
    HA353 - Load break switch 3P 200A
    HA353
    Load break switch 3P 200A
