enclosure, univers, IP65, CL 2, 1150 x 600 x 300mm, Polyester FL72S
EAN
3250612550258
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Optional accessories
-
Ventilation plate 6 products available -
Base/base element 1 products available -
Lock system 2 products available -
Accessories/spare parts for earthing and lightning 1 products available -
Document holder 3 products available -
See more 18 other products available
Complete your system
-
FL410ASteel mounting plate, Orion.Plus, 580x343 mm
-
FL411ASteel mounting plate, Orion.Plus, 580x543 mm
-
FL412ASteel mounting plate, Orion.Plus, 630x343 mm
-
FL413ASteel mounting plate, Orion.Plus, 630x443 mm
-
FL415ASteel mounting plate, Orion.Plus, 780x443 mm
-
FL416AInternal,metal mounting plate,orion.plus,930x393x2mm
-
FL417AInternal,metal mounting plate,orion.plus,930x693x2mm
-
FL418AInternal,metal mounting plate,orion.plus,1230x543x2mm
-
FL419AInternal,metal mounting plate,orion.plus,1230x693x2mm
-
FL423AInsulated mounting plate, Orion.Plus, 285x245 mm
-
FL424AInsulated mounting plate, Orion.Plus, 435x245 mm
-
FL425AInsulated mounting plate, Orion.Plus, 435x345 mm
-
FL426AInsulated mounting plate, Orion.Plus, 585x345 mm
-
FL427AInsulated mounting plate, Orion.Plus, 585x445 mm
-
FL429AInsulated mounting plate, Orion.Plus, 735x545 mm
Technical properties
Dimensions
-
Height1,150 mm
-
Width600 mm
-
Depth300 mm
-
Thickness of sidewall2 mm
Safety
-
Ingress Protection (IP) classIP65
-
Protection classIsolation class II
-
Locking type3-point lever, 4-side 8 mm
-
Impact resistance IKIK10
Equipment
-
Number of section in width2
-
Number of flange plate openings0
-
Number of rows7
Installation, mounting
-
Mounting onWall mounting
-
Suitable for outdoor usageYes
Materials
-
ColourLight grey
-
RAL code7035
-
TreatmentVarnished
-
MaterialGlass reinforced polyester
-
Surface finishMat
Cover, door
-
Number of cabinet doors1
-
Number of locks1
-
Door/cover is transparentNo
Electric current
-
Rated current400 A
