Relay 16A, 1NO+1NC, 230V~50Hz ERC218

EAN
3250612400492
Packaging
1 Piece

You have to log in with your myHager profile to see prices and to order.

Login to create a product list

You need to be logged into your myHager account to create product lists

Create an account Sign in

This product is now obsolete. However, this page remains available for information purposes. If you require any further information please contact the Technical Service Centre by email or on 01952 675689.

Relay 16A, 1NO+1NC, 230V~50Hz

ERC218

  • Accessories
  • Technical properties
  • Environmental value
  • Documentations
Download the data sheet

Complete your system

Optional accessories

  • Mech­anic accessories for low-voltage compon­ents 1 products available
  • Auxil­iary device for distri­bu­tion board devices 1 products available

Complete your system

  • Mech­anic accessories for low-voltage compon­ents
  • Auxil­iary device for distri­bu­tion board devices
  • LZ060

    Heat dissipation insert
    0.00 €  / *
  • ESC080

    Auxiliary contact 6A, 1NO+1NC
    0.00 €  / *

Technical properties

Connec­tion
  • Type of contacts
    1NC+1NO
  • Number of contacts
    2
  • Cross-sec­tion flex­ible conductor
    1 - 6 mm²
  • Cross-sec­tion rigid conductor
    1 - 10 mm²
Elec­tric current
  • Rated current
    16 A
  • Accept­able current rating AC3
    5.5 A
Capa­city
  • Number of modules
    1
Frequency
  • Frequency
    50 - 50 Hz
Voltage
  • Rated impulse with­stand voltage Uimp
    4,000 V
  • Rated insu­la­tion voltage Ui
    250 V
  • Rated oper­a­tional voltage Ue
    230 - 230 V
  • Command voltage AC
    230 - 230 V
  • Command voltage DC
    0 - 0 V
Use condi­tions
  • Oper­ating temper­ature
    -10 - 50 °C
  • Stor­age/trans­port temper­ature
    -40 - 80 °C
Use
  • Category of use
    AC-7a/AC-7b
Endur­ance
  • Number of mech­an­ical oper­a­tions
    100,000
  • Elec­tric endur­ance in number of cycles
    30,000
Power
  • Total power loss under IN
    2 W
  • Inrush power absorbed
    10.70 VA
Dimen­sions
  • Height
    83 mm
  • Width
    17.85 mm
  • Depth
    60 mm
Equip­ment
  • Number of NO contacts
    1
  • Number of NC contacts
    1
  • With switch for manual switch
    Yes
Install­a­tion, mounting
  • Nominal tight­ening torque
    1.20 - 1.20 Nm

Environmental value

We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers Learn More

RoHS conform Yes

Certifications and documents

Contactor 25A, 2NO, 230V
PDF
3,90 MB
Hager REACH declaration ERC218
PDF
Hager RoHS report ERC218
PDF

Downloads

  • Product image

    Image ERC218 | Hager

    Product Image ERC218

  • Product datasheet

    Image Hager Product data sheet ERC218 | Hager

    Hager Product data sheet ERC218

    Relay 16A, 1NO+1NC, 230V~50Hz

    PDF

  • Declaration of conformity

    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2021-09-23

    PDF
    383,45 kB
    Image Declaration | Hager

    Declaration

    Declaration of conformity International 2021-05-04

    PDF
    221,42 kB
