Series switch, common input terminal, Integro - Design Flow/Pure, chr m, galv 936552528
Login to create a product list
You need to be logged into your myHager account to create product lists
Phase out product: please contact your electrical wholesaler for availability
Complete your system
Must-have accessories
See All (10)
Accessories mandatory
-
9191501Contact protection box 2gang, Integro module inserts, grey
-
9191502Contact protection box 2gang, Integro module inserts, grey
-
91820Contact protection box Ø 45 mm, Integro module inserts, grey
-
91933Contact protection box 3gang, Integro module inserts, grey
-
91883Contact protection box Ø 49 mm, deep, Integro module inserts, grey
-
9182001Contact protection box Ø 45 mm, flat, Integro module inserts, grey
-
9191101Contact protection box 2gang vertical, deep, Integro module inserts, grey
-
9191201Contact protection box 2gang horizontal, deep, Integro module inserts, grey
-
9182002Contact protection box Ø 45 mm, Integro module inserts, grey
-
9191102Contact protection box 2gang vertical, deep, Integro module inserts, grey
Technical properties
Electric current
-
Switching current16 A
-
Rated current10 A
Voltage
-
Rated voltage250 V
Materials
-
ColourChrome
-
RAL code9006
-
Surface finishMatt
-
MaterialThermoplastic
-
TreatmentChrome plated, Coated
Identification
-
Assembly arrangementBasic element with central cover plate
Connectivity
-
Mounting typeBuilt in installation, Screw mounting
Controls and indicators
-
Number of buttons2
Dimensions
-
Built-in depth10 mm
-
Built-in depth flush-mounted boxes13 mm
Safety
-
Ingress Protection (IP) classIP20
-
Impact resistance IKIK05
Architecture
-
Control/operation elementDouble rocker
Texts
-
Installation modeFor screw fastening
-
Type of connectionWith screw terminals
-
LightingWithout lighting (cannot be illuminated)
-
Switch modeSeries
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet 936552528
Series switch, common input terminal, Integro - Design Flow/Pure, chr m, galv
PDF -
Declaration of conformity
Declaration
Declaration of conformity International 2021-12-17
PDF273,46 kB
Declaration of conformity International 2021-11-19
Declaration of conformity International 2021-12-13
PDF269,32 kB
More documentation
