IR motion det. comf 2.2 m, Q.x, ant. velvety, lacq. 85342226
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Must-have accessories
Compatible products
-
Referenced by 68 products available
Referenced by
-
10536099Frame 3gang vert., lab. field, Q.3, p. white velvety
-
10136084Frame 3gang Q.1 alu velvety, lacquered
-
10116045Contrast frame, 1gang Q.1 anthracite, velvety
-
10126084Frame 2gang Q.1 alu velvety, lacquered
-
85121200Relay insert, electronics
-
10536094Frame 3gang with labelling field vertical Q.3 alu velvety, lacquered
-
10526094Frame 2gang with labelling field vertical Q.3 alu velvety, lacquered
-
10236094Frame 3gang with labelling field horizontal Q.3 alu velvety, lacquered
-
10226094Frame 2gang with labelling field horizontal Q.3 alu velvety, lacquered
-
10516094Frame 1gang with labelling field Q.3 alu velvety, lacquered
-
10116089Frame 1gang, Q.1, p. white velvety
-
10526099Frame 2gang vert., lab. field, Q.3, p. white velvety
-
10236099Frame 3gang hor., lab. field, Q.3, p. white velvety
-
10226099Frame 2gang hor., lab. field, Q.3, p. white velvety
-
10516099Frame 1gang, lab. field, Q.3, p. white velvety
-
10156094Frame 5gang Q.3 alu velvety, lacquered
-
10156096Frame 5gang, Q.3, ant. velvety, lacq.
-
10156099Frame 5gang, Q.3, p. white velvety
-
10256014Frame 5gang with labelling field horizontal Q.1 alu velvety, lacquered
-
10246014Frame 4gang with labelling field horizontal Q.1 alu velvety, lacquered
Technical properties
Dimensions
-
Installation height2.20 - 2.20 m
-
Assembling height34 mm
Detection
-
Type of sensorMovement detector
-
Detection diameter on floor0 - 0 m
-
Detection angle adjustable45 - 90 °
Materials
-
ColourAnthracite
-
Surface finishVelvety
-
TreatmentVarnished
-
MaterialThermoplastic
Reach distance
-
Max. transmission range frontally8 m
-
Max. transmission range sideways6 m
Lighting
-
Response brightness adjustable5 - 1,000 lx
Settings
-
Response brightness adjustableYes
Use conditions
-
Operating temperature-5 - 45 °C
Safety
-
Ingress Protection (IP) classIP20
Texts
-
FunctionWith memory function for presence simulation, Teach function for response brightness via button, With keylock, Party function for switching on for 2 hours
-
ProtectionWith dismantling protection
Connectivity
-
ConnectableYes
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet 85342226
IR motion det. comf 2.2 m, Q.x, ant. velvety, lacq.
PDF -
Installation manual
Manual for 8534xx - IR motion detector comfort (EN, 2022-04)
Installation manual en-GB 2022-04-28
PDF1,89 MB -
Declaration of conformity
Declaration of Conformity
Declaration of conformity International 2021-02-15
PDF1,01 MB
Declaration of Conformity
Declaration of conformity International 2021-02-15
PDF1,01 MB
More documentation
