TS Sensor IBC Stat Conf 2G Glass Pol Whi • 75642130 | Hager
Location Turkey

  • Better buildings. Better tomorrows.

    • Menu
    Account
    EAN
    4011334383987
    Packaging
    1 Piece

    KNX glass sensor 2g thermostat, display, intg bus coupl. ,KNX-TS sensor, p.wh. 75642130

    Important information before ordering:
    This product requires to be configurated before it can be ordered.
    The configuration must be completed using our online configurator, which is accessible directly from this page.

    Complete your system

    Optional accessories

    • Accessor­ies/s­pare parts for room ther­mo­stat/c­lock ther­mo­stat 1 products available

    Technical properties

    Install­a­tion, mounting
    • Mounting on
      Flush mounting
    Use condi­tions
    • Oper­ating temper­ature
      -5 - 45 °C
    Func­tions
    • With room temper­ature controller
      Yes
    Power
    • Current consump­tion
      23 mA
    Dimen­sions
    • Built-in depth
      24.20 mm
    • Built-in depth flush-­mounted boxes
      27 mm
    • Height
      160 mm
    • Width
      86 mm
    • Depth
      37.70 mm
    Equip­ment
    • Number of actu­ation points
      6
    Controls and indic­ators
    • With LED indic­a­tion
      Yes
    Mater­ials
    • Colour
      Polar white
    • RAL code
      9010
    • Material
      Glass
    • Surface finish
      Glossy
    Accessories
    • Has labelling field
      No
    Screen
    • With display
      Yes
    Texts
    • Func­tion
      For switch, push-but­ton, dimmer, blind and ther­mo­stat func­tions, With valve protec­tion func­tion
    • Install­a­tion mode
      For vertical mounting
    • Oper­ating mode
      Controller oper­ating modes: comfort, standby, night and frost/heat protec­tion mode
    • Temper­ature
      Addi­tional connec­tion for external temper­ature sensor, Temper­ature meas­ure­ment via internal Temper­ature sensor or external commu­nic­a­tion object
    • Voltage
      Oper­a­tion with non-choked output of KNX voltage supply possible (pay atten­tion to current consump­tion), Separate auxil­iary power supply needed
    Scope of delivery
    • Bus connec­tion included
      Yes

    Environmental value

    We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More

    RoHS conform Yes
    REACh-SVHC free Yes

    Certifications and documents

    REACH declaration 75642130
    PDF
    RoHS report 75642130
    PDF

    Downloads

    More documentation
