Power supply 1x 30V DC KNX + 1x 24V DC TXA114
EAN
3250616048997
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Complete your system
Compatible products
-
Referenced by 30 products available
Referenced by
-
75643065Touch sensor 3gang thermostat, display, intg bus coupl. unit, KNX-R.1, glass bl.
-
75642039 -
75643139 -
75643155Touch sensor 3gang thermostat, display, intg bus coupl. unit, KNX-R.3, glass bl.
-
75642155Touch sensor 2gang thermostat, display, intg bus coupl. unit, KNX-R.3, glass bl.
-
75643150Touch sensor 3g thermostat, display, intg bus coupl. , KNX-R.3, glass p.white
-
75642150Touch sensor 2g thermostat, display, intg bus coupl. , KNX-R.3, glass p.white
-
75643165Touch sensor 3gang thermostat, display, intg bus coupl. unit, KNX-R.1, glass bl.
-
75642165Touch sensor 2gang thermostat, display, intg bus coupl. unit, KNX-R.1, glass bl.
-
75643160Touch sensor 3g thermostat, display, intg bus coupl. , KNX-R.1, glass p.white
-
75642160Touch sensor 2g thermostat, display, intg bus coupl. , KNX-R.1, glass p.white
-
75643055Touch sensor 3gang thermostat, display, intg bus coupl. unit, KNX-R.3, glass bl.
-
75642055Touch sensor 2gang thermostat, display, intg bus coupl. unit, KNX-R.3, glass bl.
-
75643050Touch sensor 3g thermostat, display, intg bus coupl. , KNX-R.3, glass p.white
-
75642050Touch sensor 2g thermostat, display, intg bus coupl. , KNX-R.3, glass p.white
-
80440100KNX thermostat, colourdisplay, intg bus coupling unit, KNX
-
75642065Touch sensor 2gang thermostat, display, intg bus coupl. unit, KNX-R.1, glass bl.
-
75643060Touch sensor 3g thermostat, display, intg bus coupl. , KNX-R.1, glass p.white
-
75642060Touch sensor 2g thermostat, display, intg bus coupl. , KNX-R.1, glass p.white
-
TG053AWeather station KNX GPS
Technical properties
Capacity
-
Number of modules4
Connectivity
-
With bus system KNX radioNo
Electric current
-
Output current320 mA
Voltage
-
Operating voltage230 - 230 V
-
Output voltage28 - 32 V
Connection
-
Cross-section flexible conductor0.75 - 2.5 mm²
-
Cross-section rigid conductor0.75 - 2.5 mm²
Use conditions
-
Operating temperature-5 - 45 °C
Frequency
-
Frequency50 - 60 Hz
Texts
-
FuseWith electronic short-circuit and overload protection
-
JunctionProtected earth conductor must be connected
-
Type of connectionWith quickconnect plug-in terminals
Power supply
-
Supply voltage230 V AC
Environmental value
We are committed to bettering our environmental performance by reducing our footprint while acting as a sustainability enabler for our customers. Learn More
Certifications and documents
Downloads
-
Product datasheet
Hager Product data sheet TXA114
Power supply 1x 30V DC KNX + 1x 24V DC
PDF -
Installation manual
Module alimentation TXA114
Installation manual en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, nn-NO, pl-PL, pt-PT, sv-SE 2020-01-01
PDF409,38 kB -
KNX product database
KNX product database da-DK, en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, pl-PL, pt-PT 2020-01-01
KNXPROD30,81 kB
KNX product database da-DK, en-GB, es-ES, fr-FR, de-DE, it-IT, nl-NL, pl-PL, pt-PT 2020-01-01
VD514,64 kB
