Bar/Cable-through Current Transformer BG 213 50/5A 1,5VA Class 1 SRA00505
EAN
4049857063857
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Type of productplug-in current transformer
Functions
-
Precision class1
Main electrical features
-
Frequency50/60 Hz
Voltage
-
Rated insulation voltage3 kV
Electric current
-
Maximum current of primary50 A
-
Maximum current of secondary5 A
-
Primary current50 A
Dimensions
-
Depth of installed product30 mm
-
Height of installed product78 mm
-
Width of installed product60 mm
-
width of opening20 mm
-
Height of opening20 mm
-
Bar size20x10 mm / 15x15 mm / Rundleiter d = max. 20 mm
-
Diameter of opening20 mm
Power
-
Total power loss under IN0.5 W
Connection
-
Connection cross-sect. flexible conductor1,5 / 6mm²
-
Connection cross-sect. rigid cable1,5 / 6mm²
-
Type of connectionscrew
Accessories included
-
With copper railNo
Equipment
-
Number of inputs1
-
With shock protectionYes
Use
-
Transformation Ratio50A ; 5A
Standards
-
Certified productno
Safety
-
REACH conformYes
-
RoHS conformYes
-
Halogen freeYes
Use conditions
-
Operating temperature-40…40 °C
-
Storage/transport temperature-40…40 °C
Downloads
-
Product image
-
User brochure
Energy Meters Brochure
PDF15 MB -
Technical brochures
Energy Meters Specifications and Technical Guide
PDF1 MB -
Product data sheet
