Motorized changeover switch 4P 63A 400V HIC406A
EAN
3250613191221
Packaging
1 Piece
Login to create a product list
You need to be logged into your myHager account to create product lists
Technical properties
Architecture
-
Type of orderNot applicable
-
Number of poles4 P
-
Type of pole4 P
-
Type of caseFixed built-in
Functions
-
Reversing switchYes
Controls and indicators
-
Motor drive integratedYes
Main electrical features
-
Rated operational voltage Ue380 / 415 V
-
Frequency50/60 Hz
Electric current
-
Rated current63 A
-
Short-circuit current with gI-gG fuses50 kA
-
Rated short-time withstand current 1s4 kA
-
Rated operational current in AC23 category A63 A
Power
-
Total power loss under IN3.6 W
-
Power loss per pole at In1.2 W
-
Contact rating with 400 V in AC141 kW
Cover, door
-
InterlockableYes
Installation, mounting
-
Tightening torque4 - 4.4 Nm
Connection
-
Type of connectionwith screw
Equipment
-
Number of auxiliary contacts as normally closed contact0
-
Number of auxiliary contacts as normally open contact0
-
Number of auxiliary contacts as change-over contact0
-
Motor drive optionalNo
Standards
-
Standard textIEC 60947-3 ; IEC 60947-6
Safety
-
REACH conformYes
-
RoHS conformYes
-
Halogen freeNo
